• Model NO.：4992A
• Power Source：100-240V
• Weight：Less Than 2.6kg
• Installation：Direct Connected
• Customized：Non-Customized
• Power：Less Than 25W
• Transport Package：Packing Case
• Specification：W*H*D=295mm*195mm*70mm
• Trademark：Ceyear
• Origin：China
• HS Code：9030849000
• Production Capacity：500 Pieces , Year

Frequency
characteristics Option 001 (default)Option 002Frequency  Range2MHz~1000MHz (Source 1)


 2MHz~2700MHz (Source 1)


 2MHz~400MHz (Source 2,ANT output)2MHz~400MHz (Source 2, ANT
Output)Frequency   Resolution1HzPrecisionIdentical frequency standard
Identical Frequency standardAmplitude
characteristicsOutput Level Range-5dBm~-55dBm (SWR,Source 1)-5dBm~-65dBm (SWR,Source 1,
2MHz~2.2GHz)-10dBm~-65dBm (SWR,Source 1,
2.2GHz~2.7GHz)-5dBm~-100dBm (ANT,Source 1)-5dBm~-100dBm (ANT,Source 1,
2MHz~1.8GHz)-15dBm~-100dBm (ANT,Source 1,
1.8GHz~2.7GHz)-50dBm~-125dBm (T/R,Source 1)-50dBm~-120dBm (T/R,Source 1,
2MHz~2.2GHz)-55dBm~-120dBm (T/R,Source 1,
2.2GHz~2.7GHz)0dBm~-100dBm (ANT,Source 2)-5dBm~-100dBm (ANT,Source 2)Spectrum puritySideband Phase Noise≤-95dBc/Hz (Frequency offset 20kHz)≤-90dBc/Hz (1GHz@20KHz)≤-80dBc/Hz (2.7GHz@20KHz)Harmonic Spurious≤-30dBcInternal AM
characteristicsFrequency Range30Hz~5kHz (20Hz~20kHz is available)AM Range0~100%
0~100%Modulation Accuracy±(5%×modulation depth+2%)
(150Hz~5kHz modulation rate, 10%~90% modulation depth)External AM
characteristicsAudio InputSwitching Load150Ω,600Ω,1kΩ,High ZInput Level0.05Vp~3VpFrequency Range300Hz~5kHzMicrophone InputLevel Range20mVrms~350mVrmsFrequency Range300Hz~3kHzAM Range0~80%Internal FM
characteristicsFrequency Range30Hz~5kHz(20Hz~20kHz is available)Frequency Offset RangeMax. 100kHzPrecision±5%(100kHz Frequency offset,150Hz~5kHz modulation rate )External FM
characteristicsAudio InputSwitching Load150Ω,600Ω,1kΩ,High ZInput Level0.05Vp~3VpFrequency Range300Hz~5kHzGradientPositive voltage generates positive
Frequency offsetMicrophone InputLevel Range20mVrms~350mVrmsFrequency Range300Hz~3kHzFrequency Offset Range0Hz~80kHzGradientPositive voltage generates positive
Frequency offset
Double audio sources(Audio 1and Audio 2)(T/R broadband input RF power)Measurement Range10dBm~43dBm (0.01~20W)Max. Input LevelAt +25ºC and 20W/43dBm, continues for 10 min., or sends out alarm when overheatPrecision±1dB(20~43dBm)(Built-in attenuator)RF Frequency Error Meter Capture Range±200kHzResolution1HzAccuracyTime base ±2HzIntensity Meter Of Signals Received Measurement RangedBm-110dBm~+43dBmAvailable RF Level RangeT/R port-50dBm~+43dBmANT portOption 001Option 002-110dBm~-10dBm-110dBm~-10dBm(2MHz~1GHz)-100dBm~-10dBm(1GHz~2.7GHz)Precision±3dB
Demodulation meter-80dBm~+50dBm
-80dBm~+50dBmResolution Bandwidth Range10Hz~30kHz (1, 3, 10 steps)
10Hz~30kHz(with 1, 3, 10 step)Average Noise Level Displayed-120dBm (typical value, 10kHz Frequency width)
-120dBm(typical value,10kHz Frequency width)


Audio meterAudio input level20mVp~3Vp(Measurement range 1)2Vp~30Vp(Measurement range 2)Precision±(5%´measurement value+5mV)(Measurement range 1)Distortion(THD) Display range0~100%Resolution0.1%Precision±(5%´ measurement value +0.1%),(within 1%~20%)SINAD Display Range0~40dBResolution0.1dBPrecision±1.5dB, (within 8dB~35dB)
DVM meterInput Level20mVp~3Vp(Measurement range 1)2Vp~30Vp(Measurement range 2)Precision±10%(Measurement range 1)
Audio oscilloscope(option)External audio, DVM input, demodulation signalsSweep line1Marker2TriggerTypeAuto, standard, singlePulse edgeRising edge, falling edgeLevel can be triggered-60V~+60V(setting depends on measurement range)HorizontalRange0.2ms/lattice to 50ms/lattice, in the sequence of 1/2/5Precision±3%VerticalRange10mV~20V/lattice,in the sequence of 1/2/5Precision±10%, within the whole rangeCouplingAudio inputACDVM inputAC, DCInput ImpedanceAudio input150Ω, 600Ω, 1kΩ, high impedanceDVM input1MΩBandwidth20kHz
Cable testOperating Temperature-10ºC~+50ºCStorage Temperature-40ºC~+70ºCSize295mm (W)×195mm (H)×70mm (D)Weight≤2.6kgPower Consumption≤25W(exclude battery recharging)Type of Power Input
 AC, Standard AdapterInput of the adapter:100~240V, DC of 50/60HzDCVoltage:12V~18V(without the battery)
15V~18V(with the battery)
Current:4A(min.)Built-In Battery(Standard)Nominal voltage:10.8V
Nominal capacity:≥7000mAh
Input and output ports D DescriptionSignInterface typeRF Input /Output InterfaceANTBNCT/RBNCRF Output InterfaceSWRBNCAudio Output InterfaceAudio OutBNCAudio/DVM Input InterfaceAudio In/DVMBNCGPS Signal Input InterfaceGPSBNCAudio Cassette InterfaceAudio setSpecial 10-core interface
