• Model NO.：KMHW-
• Temp. Constancy：+,-0.5oc
• Humidity Constancy：+,-2.5%R.H.
• Temp. Uniformity：+,-2.0oc
• Door Size：Single Wing:W80*H180;Double Wing:W160*H180
• Controller：Touch Screen Controller
• Operation Mode：Setting, Program
• Standard Accessories：No Fuse Breaker, Over Pressure, Over Heat and Over
• Type：Material Testing Machine
• Load Way：Electronic Load
• Loading Method：Static Load
• Display：Digital
• Control：Computer Control
• Transport Package：Strong Plywood Case, Meet International Standards
• Specification：Standard and Customized
• Trademark：KOMEG
• Origin：Dongguan, China
• HS Code：90321000
• Production Capacity：1000 Sets,Year

SPECIFICATIONSNote: We reserve the right to change specifications without prior noticeModelKMHW-468131721Volume(m³)912.916.816.835.213.3Interior DimensionsW(mm)210030003900300039004800H(mm)210021002100210021002100D(mm)205020502050430043004300Exterior DimensionsW(mm)325041605050505050505950H(mm)235023502350235023502350D(mm)225022502250225045004500Safety Devices(standard)No fuse breaker, over pressureover heat and over current protection for compressor,over-temperature protection, overload protection for the blower, dry heat protectionStandard accessoriesSight window*1,cable port(portΦ50mm)*1,chamber lamp*1, status indicatorControl System Balanced Temperature & Humidity Control SystemRefrigeration systemWater CooledSemi-hermetic compressor, single-stage or cascade refrigeration system,CFC free refrigerant(HFC-507 and HFC-23)ControllerPanel7-inch LCD Touch panel, Chinese or English display selectableOperation modelProgram or fixpoint runningMemory capacity120 programs,1200steps, all repeat 999 cycles, part repeat 99 cyclesAccuracyTemp.:0.1% of F.S±1 digit  Humidity:0.1% of F.S±1 digitInputTemp.:pt-100, Humidity:pt-100 or ~5V DCVComm.port RS-232 or RS-485 (Software is an option)Temp. rangeMaximum:80ºC,120ºC;Minimum:-60ºC,-50ºC,-40ºC,-30ºC,-20ºC,-10ºC,0ºCHumidity Range10%,20%,30%~95%Temp. constancy±0.5ºCHumidity constancy±2.5%R.HTemp. uniformity±2.0ºCHumidity uniformity±5.0%R.HAmbient Temp.+5ºC~+35ºCWiring methodAC 380±10%50Hz,3 phase 4 wires +Ground WiresHeat uptime +20ºC~+80ºC, Within 60 minPull downtime +20ºC~-55ºC -40ºC-20ºC-10ºC ,Within 120 or 90 or 60  minInterior materialStainless Steel Plate(SUS 304)Exterior materialBaked Painting Steel Or Stainless steel(SUS304)Insulation materialRigid polyurethane foamDoor size (mm)Single wing:W800*H1800;Double wing:W1600*H1800;Note:
1. We reserve the right to change specifications without prior notice
2.Customized sizes and configurations available


Packaging
Each set protected with resin fiber and PP film, then put into Strong wooden case with operation manual and video inside.

After-sale service
If you face any problems in the future during the testing process we promise we will give you a reply within 48 hours and the solution provide within 3 working days. We can offer operation video and English operation muanual. We can provide video-conference. If customers require on-site service, the transport and travel expense shall be borne by the customer.
