• Model NO.：OA-408
• Ozone Generator：Silent Discharge Tube Type
• Application：Rubber
• Transport Package：Standard Export Plywood Case
• Specification：CE, ISO
• Trademark：ASLi
• Origin：China
• HS Code：85141090
• Production Capacity：100 Sets,Month

ModelOA-80OA-408OA-800Internal Dimensions WxHxD (mm)400x500x400600x850x8001000x1000x800External Dimensions WxHxD (mm)950x1650x9501200x1950x13501600x2000x1450Temperature RangeRT+10°C~+65°C

Control Accuracy
of Temperature

±0.5°C

Distribution Uniformity
of Temperature

±2.0°C

Analytic Accuracy
of temperature

0.1°COzone Concentration (pphm)1~1000, adjustableDeviation of Ozone Concentration≤10%Ozone GeneratorSilent discharge tube typeInternal and External MaterialMaterial of the inner box is SUS 304# stainless steel, of the outer box is stainless steel or see cold-rolled steel with paint coated.Insulation MaterialPolyurethane rigid foam / superfine glass fiber cottonSecurityLeakage, short circuit, over-current protectionPowerAC 220V

Ozone laboratory test equipment Features:

1. Stainless steel inside and outside
2. Outside made iron with powder coating
3. Durable ozone generator
4. Insulation material is High-density glass fiber cotton
5. Bottom is universal round wheel and fixed foot
6. Window materials is multilayer steel-glass, the inside is chip conductive


Safety protection device:
1. the refrigeration system: The compressor overheating/ Compressor flow/Compressor overpressure/ Cooling fan overheating/ The compressor oil pressure protection
2. test chamber: Adjustable overtemperature/Air conditioning channel overtemperature limit/ Fan motor overheating.
3. the other: The total power phase sequence and the lack of protection /Electric leakage protection/Dry heating protection/ Overload and short circuit protection/ Overtemperature protection power.

Picture display function
1. In scene dialogue, no key presses, direct touch screen option.
2. Set the temperature and humidity (SV) and the actual value (PV) display directly.
3. Ozone concentration. Set (SV) and the actual value (PV) display directly.
4. Running total time accumilate function.
5. Temperature and humidity settings to program graphical curve shows a real-time curve display program execution function .
6. English and Chinese language available.
7. Troubleshooting tips showed.
8. The screen can be adjusted for backlight.
9. Screen protection for timing, closed set the TIMER or manually.

Packaging & Shipping

Package: PP film first, and then 10mm foam between machine and the case, and outside is standard export plywood case.

Our Services

1.High quality guarantee.
2.Shipment with professional documents.
3.Packing as your request, with photo before shipment.
4.Reply within 48 hours and provide solution within 3 working days
5.Professional after-service from our engineers.
6.Warranty period 12 monthes.
Our concept:
1.Client is first. We are trying to bring maximum profit to our clients and offer best quality products
2.Credibility is the most important.
3.Quality control is our life.
4.Great sense of responsibility.
