• Model NO.：TTR-I
• Accuracy Grade：Na
• Load Way：Electronic Load
• Loading Method：Dynamic Load
• Display：Digital
• Control：Computer Control
• Weight：0-100Kg
• Power Source：AC220V
• Oil Cylinder Position：Na
• Item Name：Transformer Turns Ratio TTR Meter
• Application：Test Turn Ratio and Group Vector of Transformer
• Reference Standard：IEC76--1, IEC60044
• Ratio Measurement Range：1-10000
• Group Measurement：1-12
• Test Voltage：AC 0~80V
• Size：400mm*350mm*200mm
• Power Supply：220V, 50Hz
• Transport Package：Packed in Veneer Case
• Specification：Refer to the technical specifications
• Trademark：DELTA
• Origin：China
• HS Code：9031809090
• Production Capacity：100 Sets,Month

Basic Info.

Model NO. TTR-I Accuracy Grade Na Load Way Electronic Load Loading Method Dynamic Load Display Digital Control Computer Control Weight 0-100Kg Power Source AC220V Oil Cylinder Position Na Item Name Transformer Turns Ratio TTR Meter Application Test Turn Ratio and Group Vector of Transformer Reference Standard IEC76--1, IEC60044 Ratio Measurement Range 1-10000 Group Measurement 1-12 Test Voltage AC 0~80V Size 400mm*350mm*200mm Power Supply 220V, 50Hz Transport Package Packed in Veneer Case Specification Refer to the technical specifications Trademark DELTA Origin China HS Code 9031809090 Production Capacity 100 Sets/Month

Product Description

Single Phase or Three Phase Current Transformer Turns Ratio TTR Meter

Introduction:

1. TTR-I Transformer Turns Ratio TTR Meter is designed according IEC76-1 and IEC60044.
2. TTR-I Transformer Turns Ratio TTR Meter can be applied to test the turns ratio and group vector of single or three phase transformer.
3. The connection group of three phase transformer also can be calculated with the ratio.
4. All parameters can be measured in one test for three phase transformer.

Functions:

Parameters Testing / Type of Transformer	Single Phase Power Transformer	3 Phase Power Transformer	CT	PT
Turns Ratio Testing	Yes	Yes	Yes	Yes
Phase Angle Testing	Yes	Yes	Yes	Yes
Polarity Testing	Yes	Yes	Yes	Yes
Vector Group Testing	/	Yes	No	No

Specifications:

No.	Item name	TTR-I Transformer Turns Ratio TTR Meter
1	Ratio measurement range	1-10000
2	Group measurement	1-12
3	Phase measurement error	1 degree
4	Ratio measurement error	1-2000 ± 0.2%RDG   2000-10000  ± 0.5%RDG
5	Test voltage	AC 0~80V continuously, frequency 50Hz
6	Power supply	AC220V ± 10%, 50Hz/60Hz
7	Environment temperature	0-50°C
8	Humidity	≤85%RH
9	Size	400mm*350mm*200 mm
10	Weight	7kg
11	Length of test cables	8 meters
