Reliable Performance and Capabilities Climatic and Burn-in Chambers

Guangdong Komeg Industrial Co., Ltd.
  • Power Supply：380V ,220V
  • Certification：CE, ISO
  • Warranty：1 Years
  • Interior Dimensions (D*W*H)：W 2000 X H 2050 X D 2000 mm
  • Dimensions(D*W*H)：W 2450 X H 2500 X D 2100 mm
  • Heater Power：2kw

Base Info

  • Model NO.：Burn-in room
  • Temp. Range：Rt+20+100c
  • Temp. Constancy：+-0.5c
  • Temp. Uniformity：+-3c
  • Test. Capacity：88PCS,Cycle
  • Controller：LCD Touch Screen
  • Items：Burn-in Room
  • Volume：Can Be Customized
  • Transport Package：Strong Plywood Case, Meet International Standards
  • Specification：Standard and Customized
  • Trademark：KOMEG
  • Origin：Dongguan, China
  • HS Code：90321000
  • Production Capacity：1000 Sets Per Yesr

Description

Structure and material1. Interior sizeW 2000× H 2050× D 2000 mm  (useful space)2. Exterior sizeAbout W 2450× H 2500 × D 2100 mm (external dimensions without protruding bulges of the machine)3. DoorSingle door, size W900× H1900mm, with windows ( specific size, please subject to the final design ) 4. Interior materialColor steel plate5. Exterior materialColor steel plate6. Insulation Material50mm high-density rigid PU foam ( total for 5 pcs of insulation board, the ground without insulation board)7. HeatingExplosion-proof fin heat sink heater8. Air supply systemForced circulation air supply and air - conditioning box supply9. Indoor lightingInterior lighting 2 style10. Cable portΦ50mm*2 located on both sides (each*1) with a rubber stopper and plastic cover

Features

1. Standard combined design.
2. SUS#304 stainless steel, firm structure, waterproof design.
3. Suitable for the test with large quantity and volume products.
4. Adopt imported large LCD Chinese/English microcomputer temperature controller, easy setting, strong function.
5. Standard RS-232C communication interface device.
6. Unique circulation duct design.
7. Comprehensive security control design, adopt intelligent PID+SST/SCR inverse two-way synchronous output, including the slope of the advanced control logic.
8. Heating box and explosion-proof heater design, advanced PID servo control, security, stability, and reliability.
Reliable Performance and Capabilities Climatic and Burn-in ChambersReliable Performance and Capabilities Climatic and Burn-in ChambersReliable Performance and Capabilities Climatic and Burn-in Chambers

Packaging:

The climatic thermal shock test chamber is covered with air bubble film before put them into strong plywood cases, which not only has good shock absorption, impact resistance, heat sealing, and also has the advantages of nontoxic, odorless, moisture corrosion, crash-proof, etc.

After-Sales Service

* If you face any problems in the future during the testing process, we promise we will give you a reply within 48 hours and solution provide within 3 working days. We can offer operation video, English operation manual, and video-conference. If customers require on-site service, the transport and travel expense shall be borne by the customer.
