• Model NO.：KMH-S series
• Humidity Constancy：+,-2.5%R.H.
• Temp. Uniformity：+,-2.0oc
• Humidity Uniformity：+,-5.0%R.H.
• Heat up Time：-70oc~+100oc Within 60mins
• Pull Down Time：+20 Oc~-70 Oc Within 80mins
• Equipment Power：10.6kw
• Power：AC380+,-10% 50Hz 3phase4wires+Groud Wires
• Transport Package：Strong Plywood Case, Meet International Standards
• Specification：Standard and customized, ISO9001, SGS, CE, TUV, UL
• Trademark：KOMEG
• Origin：Dongguan, P. R. China
• HS Code：90321000
• Production Capacity：1000 Sets,Year

Environmental Temperature and Humidity ChamberSpecifications ( at +20°C  room temp.  Or+25°C  water temp with empty load)ModelKMH-S series225S408S800S1000SInterior sizeW(mm)70070010001000H(mm)70075010001000D(mm)4808008001000Exterior sizeW(mm)98098012801280H(mm)1890194021602160D(mm)1460174017501950Weight(KG)330450550650Temp. range -70 °C ~+150°C Humidity Range20 ~ 98&R.H.Temp. constancy±0.5ºC   Humidity constancy±2.5%R.HHumidity uniformity±3.0%R.H±5.0 % R.HHeat uptime -70°C  ~ +100°C, within 60 minPull downtime +20°C  ~ -70°C, within 80 minEquipment Power9.5KW10.6KW18.5KW18.5KWAmbient Temp.5ºC  ~+35ºC  Standard accessoriesSight window*1,  cable port(portΦ50mm)*1,   shelves*2,    chamber lamp*1,    power cable *2mSafety device  (standard)No fuse breaker, overpressure overheat and over current protection for compressor,
Over temp. protect, overload protect of the blower, dry heat protectionControl SystemBalanced Temperature & Humidity Control SystemRefrigeration systemAir Cooled (Water Cooled Type is an option)Hermetic compressor, Cascade Refrigeration,
CFC-Free refrigerant(HFC-507/HFC-23)ControllerPanel:7-inch LCD Touch panel,    Chinese or English display selectableOperation model: Program or fixpoint runningMemory capacity :120programs,1200steps,All repeat 999 cycles, part repeat 99 cyclesInterior materialStainless Steel Plate ( SUS 304 )Exterior materialBaked Painting Steel Or Stainless steel(SUS304)Insulation materialRigid polyurethane Foam and Glass Fiber WoolSystemBalanced & Humidity Control SystemWiring methodAC 380±10 %  50Hz,3 phase 4 wires +Ground WiresNote:
1. We reserve the right to change specifications without prior notice
2. Customized sizes and configurations available
Benefits more than you can get from another supplier.
1)Delicate touch and excellent user experience
2)Unique and compact design, top-grade appearance, stable performance and easy operation.
3)Can simulate a wide range of temperature and humidity environments
4)Capable of testing large components, assemblies, and finished products
5)Customized sizes and configurations available
6) 1-year warranties
