• Model NO.：KMH-1000L
• Humidity Constancy：+,-2.5%R.H.
• Equipment Power：14.5kw
• Refrigeration System：Hermetic Compressor, Cascsde Refrigeration CFC
• Humidity Uniformity：+,-5.0r.H.
• Heat up Time：-40oc~+100oc Within 60mins
• Pull Down Time：+20 Oc~-40 Oc Within 80mins
• Power：AC380+,-10% 50Hz 3phase4wires+Groud Wires
• Transport Package：Strong Plywood Case, Meet International Standards
• Specification：Standard and Customized
• Trademark：KOMEG
• Origin：Dongguan, P. R. China
• HS Code：90321000
• Production Capacity：1000 Sets,Year

ModelKMH-1000L1000L chamber volumeTemp. range -40°C ~150°C Display resolution0.1°CTemperature stabilityHigh±0.5°C, low ±1.0°CTemperature uniformity ±2.0°CHeat uptime -40°C ~+100°C, within 45 minPull downtime +20°C ~-40°C, within 60 minHumidity range20~98%R.H,(standard),   '10~98%R.H,(with humidifier)Humidity constancy±2.5%R.HHumidity uniformity±3.0%R.HInterior Dimension(mm)1000W*1000H*1000D Exterior Dimension(mm)1280W*2160H*1950DInterior materialStainless Steel Plate(SUS 304)Exterior materialBaked Painting Steel Or Stainless steel(SUS304)Insulation materialRigid polyurethane Foam and Glass Fiber WoolTotal power  16KW(heater 6KW included)Max current35.3AWater Consumption2.5L/hrAmbient Temp.+5°C ~+35°C Power Supply AC 380V±10%50Hz,3 phase 4 wires +Ground WiresWeight 600KGSight window size460*560mmSample holder 2 pcsFittingscable port(portΦ50mm)*1, chamber lamp*1, power cable *2mSafety device  (standard)No fuse breaker, overpressure, over heat&over current protect, over temp. protect, overload protect for the blower, dry heat protect Control SystemBalanced Temperature & Humidity Control (BTHC)SystemRefrigeration systemAir Cooled (Water Cooled is an option)Hermetic compressor  Hermetic compressor                                                                                                            Single stage refrigeration system,                                                                                               CFC-Free refrigerant(HFC-507/HFC-23)CFC-Free refrigerant(HFC-507/HFC-23)Controller7-inch LCD Touch Screen panel                                                                        Operation model: Program or fixpoint runningMemory capacity :120programs,1200steps,All repeat 999 cycles, part repeat 99 cyclesNote:
1. We reserve the right to change specifications without prior notice
 2. Customized sizes and configurations available
Packaging:

Each set protected with resin fiber and PP film, then put into Strong wooden case with operation manual and video inside.

After-sale service:

If you face any problems in the future during the testing process, we promise we will give you a reply within 48 hours. And we will provide a solution within 3 working days.
We can offer operation video and English operation muanual. We can provide video-conference.
If customers require on-site service, the transport and travel expense shall be borne by the customer. Kindly understanding.
