Sy7010 Color Meter High Level Accurate Measurement Portable Spectrocolorimeter

Beijing Samyon Instruments Co., Ltd.
  • After-sales Service：24hrs
  • Warranty：1 Year
  • Model：Sy7010
  • Wavelength Range：400~700nm
  • Semiband Width：10nm
  • Illuminant：D65,a,F2(Cwf)

Base Info

  • Model NO.：SY7010
  • Weight：About 460g
  • Dimension：81X71X214mm
  • Optional Accessory：Printer, Test Box
  • Locating Method：Stabilizer Cross Position
  • Specular Component：Sci
  • Measuring Time：About 1.5s
  • Transport Package：Carton
  • Specification：SY7010
  • Trademark：SAMYON
  • Origin：Cn
  • HS Code：9031809090
  • Production Capacity：999 Per Week

Description

0.1Measuring TimeAbout 1.5sRepeatabilityChromaticity value: MAV/SCI, within ΔE*ab 0.1 ( When a white calibration plate is measured 30 times at 5 second intervals after white calibration)Inter-instrument ErrorMAV/SCI, Within ΔE*ab 0.4
(Average for 12 BCRA Series II color tiles)Measurement ModeSingle Measurement, Average Measurement(2-99times)Locating MethodStabilizer cross positionDimensionL*W*H=81X71X214mmWeightAbout 460gBatteryLi-ion battery, 6000 measurements within 8 hoursIlluminant Life Span5 years, more than 3 million times measurementsDisplay3.5-inch TFT color LCD, Capacitive Touch ScreenData PortUSBData StorageStandard 500 Pcs, Sample 10000 PcsLanguageSimplified Chinese, English, Traditional ChineseOperating Environment0~40ºC, 0~85%RH (no condensing), Altitude < 2000mStorage Environment -20~50ºC, 0~85%RH (no condensing)Standard AccessoryPower Adapter, USB Cable, User Guide, White and Black Calibration Cavity, Protective Cover, Wrist strap, 8mm flat apertureOptional AccessoryUSB Micro Printer, Powder Test BoxNotesTechnical parameters are only for reference, subject to the actual sale of the productCompany Profile
