• Model NO.：EPWT-10R
• Control：Computer Control
• Weight：5kg
• Power Source：220V or 120V at Customized
• Test Current：10A, 5A, 1A, 200mA, 40mA, <5mA
• Accuracy：+,-0.2 % (+,-2digits)
• Max. Resolution：0.1 Uohm
• Power：12V , 6ah Lithium Battery
• Protection Functions：Full
• Weight with Test Leads：5kg
• Oversize：323*275*135mm (L*W*H)
• Key Words：Transformer Ohmmeter
• Working Condition：Temperature:0-40 No Condensation
• Data Storage：1000 Groups
• Fuse：2A
• Max Consumption：200W
• Tester Weight：5kg
• Screen：True Color LCD
• LCD：True Colour
• Transport Package：Carton with Foam and Waterproof Plastic
• Specification：323*275*135mm (L*W*H)
• Trademark：EP Hipot Electric
• Origin：Wuhan, China
• HS Code：9030332000
• Production Capacity：2000,Year

Basic Info.

Model NO. EPWT-10R Control Computer Control Weight 5kg Power Source 220V or 120V at Customized Test Current 10A, 5A, 1A, 200mA, 40mA, <5mA Accuracy +/-0.2 % (+/-2digits) Max. Resolution 0.1 Uohm Power 12V / 6ah Lithium Battery Protection Functions Full Weight with Test Leads 5kg Oversize 323*275*135mm (L*W*H) Key Words Transformer Ohmmeter Working Condition Temperature:0-40 No Condensation Data Storage 1000 Groups Fuse 2A Max Consumption 200W Tester Weight 5kg Screen True Color LCD LCD True Colour Transport Package Carton with Foam and Waterproof Plastic Specification 323*275*135mm (L*W*H) Trademark EP Hipot Electric Origin Wuhan, China HS Code 9030332000 Production Capacity 2000/Year

Product Description

10A DC Winding Resistance Tester EPWT-10R

General Information:
DC resistance measurement is a necessary test item for semi-finished product, finished product factory test, installation, handover test and preventive test of power department in the manufacture of inductive coil such as transformer, mutual inductor, reactor and electromagnetic operating mechanism. It can effectively find out the manufacturing defects of inductive coil such as material selection, welding, loose connection parts, missing strand and broken wire, and hidden dangers after operation. In order to meet the needs of rapid measurement of DC resistance of inductive coil, our company has developed EPWT-10R DC resistance tester by using our own technical advantages. The instrument adopts a new power supply technology, with the characteristics of small volume, light weight, large output current, wide range, digital display and so on. The whole machine is controlled by single-chip microcomputer, which can automatically complete self-test, data processing, display and other functions, and has automatic discharge and discharge indication functions. The instrument has the advantages of high precision, simple operation and fast measurement of direct resistance.


Feature:

• Large output current and light weight.
• 6 output current options, and the maximum output current is 10A.
• Can convert the resistance temperature according to the set temperature.
• It has perfect protection circuit and more reliable performance.
• Lithium-ion battery power supply, easy to operate on site.
• It has sound discharge alarm to reduce misoperation.
• 4.3-inch color LCD with 480 resolution × 272 TFT true color display.
• Adopts machine line integration mode, with built-in test line, which is easy to carry.
• Large storage capacity, and can store up to 200 test records.
• With USB interface, test data can be transferred to U disk.
• The parameter setting is more perfect, which can set the transformer test winding, tap position, test phase, test object temperature, converted temperature value, etc.

Technical Specifications:

Measuring Current	10A, 5A, 1A, 200mA, 40mA, <5mA
Measuring Range	0.5mΩ-0.1Ω    (10A) 0.03Ω-1Ω        (5A) 0.06Ω-5Ω        (1A) 0.1Ω-50Ω         (200mA) 0.3Ω-200Ω       (40mA) 100Ω-100kΩ    (<5mA)
Measuring Accuracy	0.2%±2μΩ
Resolution	0.1μΩ
Power Supply	12V / 6Ah lithium battery
Working temperature	-20 ~ 40 ºC
Ambient humidity	≤80% RH, no condensation
Oversize	323*275*135mm (L*W*H)
Weight	5.0 kg (Including test leads)

More details on Transformer Ohmmeter EPWT series please contact EPHipot Electric, we have professional tech team to design correctly designed products and systems.
