Universal Pendulum Charpy and Izod Impact Tester
Dongguan Xin Bao Instrument Co., Ltd.- Mass Scope of Workpiece：<900kg
- Type：Material Testing Machine
- Maxcapacity：<1000KN
- Accuracy Grade：0.5
- Load Way：Mechanical Load
- Loading Method：Dynamic Load
Base Info
- Display：Digital
- Control：Manual Control
- Weight：100-500Kg
- Power Source：AC220V
- Pendulum Energy：1.0j, 2.75j, 5.5 J
- Impact Speed：3.5m,S
- Display Method：Color Touch Screen
- Pendulum up Angletray：150c
- Impact Center Distance：335mm
- Cutting Edge Radius：R=0.8
- Meet The Standards：ISO180-2000, ASTM D256-2010;
- Transport Package：Standard Strong Wood Case
- Specification：700*600*1400mm
- Trademark：OTS
- Origin：Guangdong, China (Mainland)
- HS Code：9024109000
- Production Capacity：248 Sets Per Month
Description
Ø Display mode: color touch screen (Chinese and English)
Ø Angle sensor brand and accuracy: original imported Omron encoder, accuracy to 0.01°
Ø Energy display accuracy: 0.01J
Ø Impact speed: 3.5m/s;
Ø Pendulum energy: 2.75J, 5.5J
Ø Pendulum angle: 150°
Ø Distance from the center of the pendulum to the impact blade: 335mm
Ø Distance from impact blade to upper plane of jaw: 22mm
Ø Included angle of blade: 75±l°
Ø Blade radius: R=0.8±0.2mm
Ø Machine weight: 85kg
Ø Power supply voltage: AC220V±10% 50HZ
Characteristic:
1. English characters LCD shows the results, the storage of test results, and has the energy loss to be automatic correction function. Simple structure, convenient operation, data accurate and reliable.
2. Automatic display test result
3. In stock, fast delivery
Meet the standards:
ISO179-2000
GB/T1043-2008
JB/T8762-1998
GB/T 18743-2002
ISO180-2000
GB/T1843-2008
JB/T8761-1998
ASTM D256-2010
Recommend ProductsCompany Profile
Manufacturing TechniqueCustomer PhotosCertificationsPacking&ShipingFAQ1.Do you offer after-sales service? How can I ask for that? And how about the warranty? Every machine from our factory has a 14-month warranty after shipment. Generally, we offer 12 months for the FREE maintenance, while considering of sea transportation, we can extend 2 months for our customers. If your machine doesn't work, you can send E-mail to us and we will try our best to find the problem by email or skype video chat if neccesary. After confirmation of the problem, we can send you new spare parts or provide on-site repair.
2.What's the delivery term?
At most of time, we have stock in the factory. If there is no stock, normally, the delivery time is 15-20 working days after deposit receipt. If you are in urgent need, we can consider making a special arrangement for you.
3.Do you accept customization service? Can I have my logo on the machine?
Yes, of course. We can not only offer standard machines, but also customized machines according to your requirements. And we can also put your logo on the machine.
4.How to install and use the product?
We will send you operating instructions, English video by Email. Or you can download on our officail website directly. Most of our machine is shipped with a whole part, which means it is already installed, all you need to do is to connect the power cable and start to use. And if possible, we can also install your machine at site.
