Two-Staion Rotor Automatic Correction Balancing Machine

Shanghai Jianping Dynamic Balancing Machine Manufacturing Co., Ltd.
  • Type：Balancing Machine
  • Load Way：Electronic Load
  • Loading Method：Dynamic Load
  • Display：Digital
  • Control：Computer Control
  • Weight：500-1000Kg

Base Info

  • Model NO.：A2WZ1
  • Power Source：AC380V
  • Length：1130 Mm
  • Width：1200 Mm
  • Height：1700 Mm
  • Gross Weight：1000 Kg
  • Transport Package：Packed in Fumigated Wood Box
  • Specification：ISO9001: 2008, CE, SGS
  • Trademark：JP
  • Origin：Shanghai China
  • HS Code：9001100001
  • Production Capacity：1000 Sets,Month

Description

Technical DataDescriptionTypeA2WZ1Main ComponentsCylinder: SMCSensor: KEYENG, OMRONServo Motor: PanasonicControl PLC: SiemensTouchsreen: NuodajiaMeasuring Instrument: Shanghai Jianping Rotor Diameter RangeRotor of 1.6 Kg or lessRotor Length: 150mmRotor Diameter: Φ25-50mmBalancing Speed 1000-3000RpmMilling MethodDouble Milling cutter &Double Drilling BitPowerAC 380VPneumatic0.4-0.6MpaResidual Unbalance EccentricityG 6.3Dimensions (L×W×H)1130×1200×1700mm
