• Model NO.：GD-2801F
• Temp.Control：Automatic(5~100)
• Features：Low Temperature Type
• Transport Package：Wooden Case for Gd-2801f Low Temperature Asphalt P
• Trademark：GOLD
• Origin：Chongqing, China
• HS Code：9031809090
• Production Capacity：100 Sets, Month

digital display to show the penetration number and two grades of timing control.

Specially designed low-temperature circulatory water bath can supply the constant temperature water into glass bath on the penetrometer. It creates a constant low temperature which can be preset for the specimen.


Circulatory water bath1Power supplyAC20V±10%, 50Hz2Bath volume8.5L3Temperature range(5.0~100.0)°C4Temperature accuracy±0.1°C5Circulatory water quantity5L/min6Pump lift1m7Maximum power consumption1000W8Dimension420mm×380mm×900mmPenetrometer1Timing controller5s or 60s can be selected. Bias within±0.1s2Needle holderHigh accuracy digital display. Easy to use and observe. It can be moved to any position.3Resolution0.01m4Penetration accuracy±1 penetration5Maximum scale600 penetration6Standard needle50mm, 2.5g±0.05g7Dimension280mm×350mm×700mm

Related products:

ModelGD-2801CGD-2801GGD-2801E1GD-2801FGD-2801IMax.Penetration600600600600600Resolution0.1mm0.1mm0.1mm0.1mm0.1mmTiming Control5,8,10,12,30,60s5,8,10,12,30,60s50,60s50,60s0~60sTemp. ControlAutomaticAutomaticAutomaticAutomaticAutomaticTest SamplesOilWaxAsphaltAsphaltAsphaltTypeCommonMultifuctionCommonSpecialFull FunctionWith Water BathYesYesYesYes, low temp.Yes, low temp.

Company  Information:

Chongqing Gold Mechanical & Electrical Equipment Co., Ltd.

We mainly design and manufacture the petroleum testing instrument
After several years' development, our products have become high intelligent and wide coverage. And our company has become one of the leading manufacturer of petroleum testing instrument .
