En 12606-1 Bitumen Paraffin Wax Content Tester by Cracking Distillation Method

Chongqing Advanced Technology Co., Ltd.
  • After-sales Service：Response in 12 Hours
  • Warranty：1 Year
  • Test Standard：En 12606-1,IP 459-1
  • Power Supply：AC(220±10%)V,50Hz
  • Heating Power：700W
  • Cooling Power：1033W

Base Info

  • Model NO.：WCT
  • Stirring Rate of Motor：1200 R,Min
  • Refrigeration Medium：F22
  • Test Temperature：-20ºC
  • Dimension：750mm×440mm×560mm
  • Display：LCD
  • Test Method：Cracking Distillation
  • Application：Bitumen Testing
  • Function：Determine Paraffin Wax Content in Bitumen
  • Color：White
  • Total Power Consumption：≤1800W
  • Transport Package：Plywood Case
  • Specification：Stainless steel
  • Trademark：AI
  • Origin：China
  • HS Code：9031809090
  • Production Capacity：20 Sets,Month

Description

1Power supplyAC(220±10%)V,50Hz2Heating power700W3Cooling power1033W4Stirring rate of motor1200 r/min5Temperature sensorPt1006Refrigeration mediumF227Temperature accuracy±0.3ºC8Working environment-30ºC~40ºC, RH<859Total power consumption≤1800W10Overall dimension620mm×500mm×1600mm
(The air flow distributor is included)



III.Accessories of WCT Paraffin Wax Content Tester

No.ItemUnitQty1Cooling and filtering device (including suction flask, sand core filter funnel, sample cooling tube, glass tube, glass rod, etc.)Set32Pyrolysis flask (With a handle)Piece33Sample tube (90 ml)Piece34Mercury thermometer (-30 ºC~+50 ºC,scale division is 0.5ºC)Piece15Dustproof cover (3 large and 3 small)PieceTotal 66Conical flask (250×24)Piece57Stopper for thermometer (Large)Piece18Silica gel tube (outer diameter Ф9×wall thickness1.5; length 400 mm)Piece39Silica gel stopper (5#: 2 pieces, 6#( Improved.): 2 pieces)PieceTotal 410Beaker (1000 ml)Piece111Graduated flask (100 ml)Piece112Stopping ring for thermometer (1#)Piece413"O" type rubber ring (Ф31×2.4)Piece314Fuse 15 A (Ф6×30)Piece315Power supply wire(Homemade)Piece116Pneumatic distributor(Including installation frame, must install it by user self)Set117Sample container hook holderPiece118Wax filter bottle(250 mL)Piece319Three way component(One into two out, with two-way valves)Piece120Transition joints(Φ12.7 turn Φ10)Piece121Rubber tube (outer diameter Ф14×wall thickness3.5)( According to the user's need to cut the tube)Meter822

Silica gel tube (outer diameter Ф18×wall thickness3.0)

(Connecting transition joints and vacuum drying box)

Centimeter8




Factory overview

En 12606-1 Bitumen Paraffin Wax Content Tester by Cracking Distillation Method
Customer Feedback

Germany
En 12606-1 Bitumen Paraffin Wax Content Tester by Cracking Distillation Method
USA
En 12606-1 Bitumen Paraffin Wax Content Tester by Cracking Distillation Method
Package
En 12606-1 Bitumen Paraffin Wax Content Tester by Cracking Distillation Method
FAQ
1.What's the delivery time?
About 15 days.

2.What's your payment terms?
30% paid by T/T in advance,70% paid by by T/T before shipping.

3.What's your guarantee terms?
The warranty of all products is 1 year.During this period,we are responsible for all faults caused by us.And we can supply life-long technical support.

4.Can you supply training?
We can supply training in our factory and online training for free.If onsite installation and training are required,please pay for tickets,accommodation and salary USD150/Day for every person.
