Asphalt Testing Machine & Laboratory Equipment Automatic Wheel tracking Device
Shanghai Changji Geological Instrument Co., Ltd.- After-sales Service：Yes
- Warranty：1 year
- Power supply：380V AC
- hz：50Hz
- Rolling speed of grinding wheel：(42 ± 1) times, min (one way)
- Test car moving distance：(230 ± 10) mm
Base Info
- Model NO.：SYD-0719C-2
- Rubber hardness of grinding wheel：78± 2 (international standard hardness)
- Displacement measuring range：(0 ~ 30) mm
- Displacement measurement accuracy：less than 0.01mm
- Test time：(60 ~ 240) min
- Tryout temperature control accuracy：± 0.5 ºC
- Works：Immersion and non-immersion test
- Temperature measuring channel number：2 channels
- Displacement sensor：3
- Can do specimen number at the same time：3
- The number of specimens of health：9
- Transport Package：by Carton or by Wooden Case
- Specification：2200mmx 960mm x1680mm
- Trademark：SHANGYI
- Origin：China
- HS Code：9021809090
- Production Capacity：1000 Sets,Month
