Transformer Capacitance Tandelta Test Equipment Cdf Tester Epjs-12kv
EP HIPOT ELECTRIC CO., LTD.- After-sales Service：Remote Guidance
- Warranty：1or 2 Years Free Warranty Longlife Service
- Max Diameter of Workpiece：<500mm
- Mass Scope of Workpiece：28kg
- Type：Universal Testing Machine
- Accuracy Grade：0.01
Base Info
- Model NO.：EPJS Series
- Load Way：Electronic Load
- Display：LCD
- Weight：28kg
- Power Source：AC220V
- Output Voltage：0.5~12kv
- Cx Accuracy：+-(Read*1%+1PF)
- Tg&Delta Accurancy：+-(Read*1%+0.00040)
- Internal Hv：3PF~50000PF,12kv 60PF-1UF,0.5kv
- External Hv：3PF~1.5UF,12kv 60PF~30UF,0.5kv
- Resolution：Max. 0.001PF,4 Significant Figures
- CVT Self Excitation LV Output：Output Voltage 3~50V,Output Current 3~30A
- Test Current Range：10ua~5A
- Setting Voltage Range：0.5~12kv
- Keywords：C&Df Tester
- Test Frequency：45, 50, 55, 60, 65Hz Single Frequency
- Test Frequency,Hz：45,55Hz, 55,65Hz, 47.5,52.5Hz Auto Double Frequenc
- Frequency Precision：+-0.01Hz
- Communiation Port：RS232
- Printer：Build-in Thermal Printer
- Transport Package：Plywood Case
- Specification：460*360*350mm
- Trademark：EP Hipot Electric
- Origin：Wuhan, China
- HS Code：9031809090
- Production Capacity：1000,Year
Description
Build-in thermal printerMore details on 12kV Capacitance and Tan Delta Tester please contact EPHipot Electric, we have professional tech team to design correctly designed products and systems.
