Insulating oil dielectric loss Tan Delta Tester
Wuhan GDZX Power Equipment Co., Ltd.- After-sales Service：Provide lifelong after-sales service
- Warranty：1 Year
- Power consumption：100W
- Size：420*380*385mm
- Total weight：21Kg
- Working power supply：AC 220V
Base Info
- Model NO.：ZX-YJS
- Power frequency：50Hz
- Transport Package：Cartons or Wooden Cases
- Specification：420*380*385mm
- Trademark：GDZX
- Origin：China
- HS Code：9026800000
- Production Capacity：50PCS,Month
Description
ZX-YJS Insulating oil dielectric loss Tan Delta Tester is mainly used for measuring dielectric loss factor and DC resistivity of liquid Insulating medium such as Insulating oil. Internal integrated dielectric loss oil cup, temperature controller, temperature sensor, dielectric loss test bridge, AC test power supply, standard capacitor, high resistance meter, DC high voltage source and other main components. The instrument uses new measurement and control technology, fully automatic temperature, temperature control, high-speed data sampling, operation, display, printing and storage processes.Technical parameters
| Measurement range | 1) Capacitance: 5pF ~ 200pF 2) Relative permittivity: 1.000 ~ 30.000 3) Medium loss factor: 0.00001 ~ 100 4) DC resistivity: 2.5MΩm~20TΩm |
| Measurement accuracy | 1) Capacitance: ±(1% reading + 0.5PF) 2) Relative permittivity: ±1% reading 3) medium loss factor: ±(1% reading +0.0001) 4) DC resistivity: ±10% reading |
| Resolution | 1) Capacitance: 0.01PF 2) Relative permittivity: 0.001 3) Medium loss factor: 0.00001 |
| Temperature range | 0 ~ 125ºC |
| Temperature measurement error | ±0.5ºC |
| AC experimental voltage | 500 ~ 2200V continuously adjustable, frequency 50Hz |
| DC test voltage | 0 ~ 500V continuous adjustable |
| Power consumption | 100W |
| Size | 420*380*385mm |
| Total weight | 21Kg |
| Ambient temperature | 0 ~ 40ºC |
| Relative humidity | ≤80% |
| Working power supply | AC 220V (1 ± 10%) |
| Power frequency | 50Hz (1 ± 10%) |
| Power consumption | < 200W |
Test cases
Company introduction
Wuhan GDZX Power Equipment Co.,Ltd.is a manufacturer of power test equipment, integrating design, production and sales, providing complete solutions for high-voltage testing and electrical testing services for various power users.The main products include:AC series resonance test device, high voltage test equipment, transformer test equipment, secondary protection / switch test equipment, cable fault tester, arrester test equipment, power metering equipment, standard source series and so on. There are many kinds of products and complete models.
Service and Warranty
Service
* Provide professional consulting service; dedicated salesman and professional technical engineer to answer customer questions.
* Ensure customer get the detailed information about the product in hand.
* Reasonable price, we trust our customers should get the worth what they paid. Quotation stamped and confirmed by Manager.
* Welcome customers visit.
* Being trustworthy, follow the requirements and ensure successful implementation of signed contracts and technical agreements.
* Focus on communication, actively communicate with users, take notes of user's questions and schedule, provide the necessary technical support.
* Move quick and efficient, professional on delivery, installation, debugging, training and others. Warranty* We maintains 100% customer satisfaction, please give us feedback if you fell anything wrong with the product, we will make it right for you.* Our products are guaranteed with one year warranty and life-long tech support.* Provide solutions within 24 hours when there is problems feedback from customer.
PACKING AND SHIPPING
(1)We will ship products within 8-20 working days after the receipt of confirmation of your payment.
(2)All products will be well packed by robust carton or wooden box so as to ensure goods can arrive safely.(3)Multiple shipping methods including express, sea freight, railway and so on for your choice, competitive shipping method will be advised to you.(4)If you go with your own forwarder, we will provide all necessary documents for customs clearance.(5)After shipping, we will remain attentive till goods well received. If you need detailed specification, please feel free to contact us.
Features
1. Electrode open circuit fault and short circuit fault auto-detection function
2. Built-in thermal printer, can do off-line printing
3. With Screen protection function to extend LCD life span
4. High precision and rapid measuring speed
