Digital Transformer Capacity No-Load Loss Test Transformer Characteristic Tester
Xi'an Xu&Hui Electromechanical Technology Co., Ltd.- Warranty：12 Months
- Power：Electricity
Base Info
- Model NO.：XHTX1318
- Certification：CE
- Customized：Customized
- Color：Yellow
- Voltage Accuracy：± 0.2%
- Capacitance：2,4μf Customized
- Working Temperature：-25 ~ 65 Degree Centigrade
- Charging Power：AC 160V ~ 260V
- Transport Package：Exported Wooden Case
- Specification：350*280*170 (mm)
- Trademark：XZH TEST
- Origin：China
- Production Capacity：2000PCS,Year
- Package size per unit product：35.00cm * 28.00cm * 17.00cm
- Gross weight per unit product：5.500kg
Description
Overview
Product Parameters
Main Technical Parameters
1. Environmental conditions
Temperature: -5 °C ~ 40 °C
Relative humidity: <95% (25 °C)
Altitude: <2500m
External interference: no special strong vibration, no special electromagnetic field
External power supply: 220VAC±10%, 45Hz~55Hz
2. Test range
Capacity: 10KV oil immersed, dry transformer: 30KVA ~ 2500KVA
35KV oil immersed transformer: 50KVA ~ 31500KVA
20KV dry type transformer: 50KVA ~ 2500KVA
35KV dry type transformer: 50KVA~2000KVA
Voltage: 0 ~ 450V (phase voltage), 0 ~ 1000V (line voltage), the instrument automatically switches the range internally
Current: 0~100A, the instrument automatically switches the range internally.
Frequency: 45Hz ~ 65Hz
3. Test accuracy
Voltage: 20~100V, ±0.2% FS; 100~450V, ±0.2%
Current: 0.5~10A, ±0.2% FS; 10~100A, ±0.2%
Power: ±0.5% (CosΦ>0.1), ±1.0% (0.02<CosΦ<0.1)
4. Insulation strength
The insulation resistance of the voltage and current input terminals to the housing is ≥100MΩ.
The working power input end is subjected to a power frequency of 2KV (effective value) between the outer housings, and it takes 1 minute to test.
Product Description
Product Parameters
Main Technical Parameters
1. Environmental conditions
Temperature: -5 °C ~ 40 °C
Relative humidity: <95% (25 °C)
Altitude: <2500m
External interference: no special strong vibration, no special electromagnetic field
External power supply: 220VAC±10%, 45Hz~55Hz
2. Test range
Capacity: 10KV oil immersed, dry transformer: 30KVA ~ 2500KVA
35KV oil immersed transformer: 50KVA ~ 31500KVA
20KV dry type transformer: 50KVA ~ 2500KVA
35KV dry type transformer: 50KVA~2000KVA
Voltage: 0 ~ 450V (phase voltage), 0 ~ 1000V (line voltage), the instrument automatically switches the range internally
Current: 0~100A, the instrument automatically switches the range internally.
Frequency: 45Hz ~ 65Hz
3. Test accuracy
Voltage: 20~100V, ±0.2% FS; 100~450V, ±0.2%
Current: 0.5~10A, ±0.2% FS; 10~100A, ±0.2%
Power: ±0.5% (CosΦ>0.1), ±1.0% (0.02<CosΦ<0.1)
4. Insulation strength
The insulation resistance of the voltage and current input terminals to the housing is ≥100MΩ.
The working power input end is subjected to a power frequency of 2KV (effective value) between the outer housings, and it takes 1 minute to test.
