• Model NO.：MHT-8
• Sample Quantity：8.4G
• Display：LCD Screen
• Color：White
• Dimension：450*450*560mm
• Weight：About 20kg
• Test Time：24 Hours
• Power Supply：AC220V 50Hz
• Pump Flow Rate：0.25g,Min
• Language：English
• OEM Service：Available
• Function：Evaluate The Tendency of Engine Oil to Form Deposi
• Transport Package：Hardboard
• Specification：Vertical type
• Trademark：AI
• Origin：China
• HS Code：9031809090
• Production Capacity：50 Sets,Month

Basic Info.

Model NO. MHT-8 Sample Quantity 8.4G Display LCD Screen Color White Dimension 450*450*560mm Weight About 20kg Test Time 24 Hours Power Supply AC220V 50Hz Pump Flow Rate 0.25g/Min Language English OEM Service Available Function Evaluate The Tendency of Engine Oil to Form Deposi Transport Package Hardboard Specification Vertical type Trademark AI Origin China HS Code 9031809090 Production Capacity 50 Sets/Month

Product Description

Introduction

MHT-8 High Temperature Deposits Apparatus is used for the engine oil thermal oxidation simulation test. The mixture of the sample and the catalyst is fully mixed uniformly, and a certain amount of air is introduced. The sample flows down spirally along the metal coil on the deposition rod, and circulates for a total of 24 hours. Weighing deposition rod before and after test is used to evaluate the tendency of engine oil to form deposits under high temperature oxidation conditions.



I.Main features

1. This MHT High Temperature Deposits Apparatus is the first in China and can replace similar foreign products;
2. The main components are imported products (temperature controller, deposition rod, gear pump, flow sensor, etc.);
3. The user can program the working time, and it will stop automatically after the test;
4. ASTM D6335, SH/T0750 method test components is optional part for this High Temperature Deposits Apparatus  ;
5. Catalyst magnetic mixing device, mixing time and mixing speed can be set;
6. Automatic electronic flow controller, accurately control the gas flow rate of 10ml±0.2ml/min;
7. All parameter settings can be performed on the touch screen, and the test can be started with one key after completion;


II.Technical specifications of High Temperature Deposits Apparatus

Applicated standard	ASTM D7097 ,ASTM D6335
Test temperature	ambient~500ºC±2ºC
Test time	24 hours
Sample quantity	8.4g
Pump flow speed	0.25g/min
Gas flow speed	10ml±0.2ml
Power supply	AC220V 50HZ
Size	450*450*560mm

  Factory overview
Customer Feedback

Germany

USA

Package

FAQ
1.What's the delivery time?
About 60 days.

2.What's your payment terms?
30% paid by T/T in advance,70% paid by by T/T before shipping.

3.What's your guarantee terms?
The warranty of all products is 1 year.During this period,we are responsible for all faults caused by us.And we can supply life-long technical support.

4.Can you supply training?
We can supply training in our factory and online training for free.If onsite installation and training are required,please pay for tickets,accommodation and salary USD150/Day for every person.
