Build-in Camera Biological Microscope
Biobase Meihua Trading Co., Ltd.- Max Diameter of Workpiece：500mm
- Mass Scope of Workpiece：<900kg
- Type：Microscope
- Maxcapacity：<1000KN
- Accuracy Grade：1
- Load Way：Electronic Load
Base Info
- Model NO.：BMB-117M
- Loading Method：Dynamic Load
- Display：Digital
- Control：Manual Control
- Weight：0-100Kg
- Power Source：AC220V
- Oil Cylinder Position：Under
- Optical System：Infinite Optical System
- Transport Package：Export Packing
- Specification：MM-5000
- Trademark：BIOBASE
- Origin：China
- Production Capacity：500 PCS , Mout
Description
Product Parameters
Specification
BMB-117M
BMB-300M
Viewing Head
Compensation Free Binocular Head, Inclined at 30°, Interpupilary Distance 48-75mm
√
√
Camera
System
Valid Pixel
1280*1024(1.3M Pixel)
√
2048*1036 (3.0M Pixel)
√
2052*1944 (5.0M Pixel)
Output Mode
USB2.0
√
√
Operation System
WINDOWS7/8 2000 / XP/ VISTA
√
√
Software
ScopeImage 9.0
√
√
Range of Viewing Field
90%
√
√
Eyepiece
WF10×/ 18
√
√
P16×/ 11
Extra wide filed eyepiece EW10×/ 20 with diopter
adjustment
Objective
Achromatic Objective 4×,10×,40×,100×
√
Infinite planAchromatic Objective 4×,10×,40×,100×
√
Nosepiece
Backward Quadruple Nosepiece
√
QuintupleNosepiece
Quadruple Nosepiece
√
Stage
Double Layers Mechanical Stage 132*142mm,Moving range 75*40mm
√
Double Layers Mechanical Stage 140*140mm Moving range 75*40mm
√
Condenser
Abbe NA1.20 with Iris Diaphragm & Fliter
√
Abbe NA1.25 sliding-in centerable condenser
√
Focusing
Coaxial Coarse & Fine Adjustment System, Range 24mm, Fine Division 0.004mm
√
Coaxial Coarse & Fine Adjustment System, Range 20mm
√
Illumination
LED 3W, Brightness Adjustable
√
Halogen Lamp 6V/ 20W, Brightness Adjustable
220V or 110V/ 6V/ 20W Halogen Lamp, Brightness Adjustable
√
Power Supply
AC110/220V±10%, 50/60Hz
√
√
Accessories
Phase Contrast Kit
Dark-Field Attachment
Polarization Attachment
Package Size
396*262*492(BMB-117M), 334*334*533(BMB-300M)
√
√
Gross Weight
7.5kg (BMB-117M), 12.5kg (BMB-300M)
√
√
