• Model NO.：TH-225-E
• Material：SUS304
• Sample Shelf：3 PCS
• Transport Package：Wooden Case
• Specification：TH Series
• Trademark：ASLi
• Origin：Guangdong, China
• HS Code：8514191000
• Production Capacity：100 Sets,Month

ModelTH-80(A~F)TH-150(A~F)TH-225(A~F)TH-408(A~F)Internal Dimension
W*H*D (mm)400*500*400500*600*500600*750*500600*850*800Internal Dimension
W*H*D (mm)950*1650*9501050*1750*10501200*1900*11501200*1950*1350Temperature RangeLow Temperature(A:25degres Celsius B:0degres Celsius  C:-20degres Celsius
:-40degres Celsius E:-60degres Celsius F:-70degres Celsius)
High Temperature 150degres CelsiusHumidity Range20%~98%R.H.(10%-98% R.H. / 5%-98% R.H ,is optional , need Dehumidifier)Indication relolution/
Distribution uniformity
of temperature and humidity0.1degres Celsius; 0.1% R.H/±2.0degres Celsius; ±3.0% R.H.Control Accuracy of
Temperature and Humidity±0.5degres Celsius; ±2.5% R.H.Temperature Rising/
Falling VelocityTemperature rising approx. 0.1~3.0degres Celsius/min ;
temperature falling approx. 0.1~1.5degres Celsius/min;
( Falling Min.1.5degres Celsius/min is optional)Inner and Outer MaterialInterior material is SUS 304# stainless steel, exterior is stainless steel or SEE
cold-rolled steel with paint coated.Insulation MaterialResistant to high temperature, high density, formate chlorine, ethyl acetum foam
insulation materialsCooling SystemWind cooling or water cooling, (single segment compressor-40degres Celsius,
double segment compressor -70degres Celsius)Protection DevicesFuse-free switch, overloading protection switch for compressor, high and low
voltage coolant protection switch, over-humidity and over-temperature protection
switch, fuses, fault warning system, water short storage warning protectionOptional AccessoriesInner door with operation hole , Recorder, Water Purifier, DehumidifierCompressorFrench Tecumseh Brand, Germany Bizer BrandPowerAC220V 1Ph 3 lines, 50/60HZ , AC380V 3Ph 5 lines , 50/60HZApprox. Weight (Kg)150180250320
Cooling Chamber Features:
1. Graceful appearance, circularly shaped body, surface treated with mist strips. Easy to operate, safe and reliable.
2. Rectangular double-paned viewing window for viewing sample under test, with interior light
3. Double-layer-insulated airtight doors, able to insulate the internal temperature effectively.
4. Water supply system that is externally connectable, convenient for refilling water into the humidifying pot and automatically recyclable.
5. French Tecumseh is used as compressor, with environment friendly refrigeration R23 or R404A
6. LCD display screen, capable of displaying the measured value as well as the set value and time.
7. The control unit has the functions of multiples segment program editing, with quick or ramp rates
Control of temperature and humidity.
8. Casters are provided for ease of mobility, with strong positioning screws.

Temperature and Humidity Test Machine Pictures:

Saftey device:
1. With no-fuse protection switch
2. Control system with phase sequence protection and low voltage electrical protection.
3. With over-heat protection switch.
4. Over load protection device for refrigeration compressor.
5. Refrigeration compressor high and low voltage protection switch.
6. Refrigeration compressor over oil pressure protection.
7. Lack of Anti-phase protection system.
8. Overload protection for circulation fan motor.

Our advantage
1.Professional technology support.
2.Full experience of large numbers containers loading in Chinese sea port.
3.Fast shipment by reputed shipping line.
4.Best service after shipment with emails.
5.We are professional test equipment manufacturer in China with excellent experience and skills, also have best quality products

Please feel free to contact us if any doubt about Programmable constant temperature humidity aging testing chambers.
