LCD Integrated Cable Fault Locator
Tianjin Grewin Technology Co., Ltd.- Test Mode：Instant Test
- Usage：Network Cable Tester, Audio Cable Tester, Coaxial Cable Tester, Digital Cable Tester
Base Info
- Model NO.：Integrated Cable Fault Locator
- Test Region：Unformed
- Cable Type：Unshielded
- Power：Electricity
- Certification：CE, RoHS, CE, ISO, RoHS, GS
- Customized：Non-Customized
- Color：Orange
- Condition：New
- Type：Energy Meter
- Type1：Pclr 8000 Remote Service Integrated Locator
- Sampling Frequency：100MHz
- Low Voltage Impulse：1m
- Impulse Current：4m
- Voltage of Low Voltage Impulse：30V
- Distance Measurement Range：30km
- Blind Zone：2m
- Volume：270*150*210mm
- Weight：1.5kg
- Electric Equipment：Single-Phase
- Transport Package：Export Standard Carton or Customize Strong Pallet
- Specification：PCLR 8000 Remote Service Integrated Locator
- Trademark：PCLR 8000 Remote Service Integrated Locator
- Origin：China
- HS Code：9028901000
- Production Capacity：4000 PCS Per Month
Description
Fault distance locating Distance measurement mode Low voltage impulse
Impulse current Sampling frequency 100MHz Resolution Ratio Low voltage impulse:1m
Impulse current:4m Voltage of low voltage impulse 30V Distance measurement range 30km Blind zone 2m Audio magnetic synchronization pin-pointing: Audio signal transmission band Mid-frequency 400Hz ,bandwidth 200Hz. Gain of signal channel 80dB Accuracy of pin-pointing 0.1m Power supply: Battery built-in Li-ion battery pack, nominal voltage 7.4V,Capacity 3000mAH Power consumption 400mA ,work time reach 6 hours Charger Input AC100-240V, 50/60Hz; output 8.4V, DC 1A Charge time <4 hours Display Main unit 320*240 LCD Other Volume 270*150*210mm Weight 1.5kg Working condition Tem. -10ºC-40ºC Humidity 5-90%RH Elevation <4500m
Tianjin Grewin Technology Co.,Ltd have twenty years producing experience, located in Tianjin , China, our company have professional design term, advanced technology and equipment, especially pay great attention to its business philosophy "Quality and Honesty First". Grewin is specialized in the design and manufacture of intelligent power meter and testing device, such as Three/single Phase Multi function Meter, Power Monitoring device,Intelligent Pipe Locator,Route tracing/Cable identification/depth measurement/grounding fault location and so on;especially the EPM and TPM product got inland and over sea's clients praise, and established OEM or ODM relationship. Our products have passed and obtained ISO9001 certificate ,CE certificate,SGS approval, and IEC report. We have developed good cooperative relationship with valued customers around the word, have first class product quality and one basket value-added after sales service along with the fast efficient solution. Grewin has won its brand in word wide.
