New Design Multiple Pulse Cable Fault Distance Locator

Xi'an Xu&Hui Electromechanical Technology Co., Ltd.
  • Warranty:1 Year
  • Test Mode:Saved Test

Base Info

  • Model NO.:XHGG502
  • Usage:Network Cable Tester, HDMI Cable Tester, Audio Cable Tester, Coaxial Cable Tester, Digital Cable Tester
  • Test Region:Forming Cable
  • Power:Electricity
  • Certification:CE, Ios
  • Customized:Customized
  • Color:Black
  • Reading Resolution:0.1m
  • Pulse Amplitude:400vpp
  • System Test Accuracy:Less Than 0.5m
  • Temperature:-25ºC~+55ºC
  • Transport Package:Wooden Box with Foam Inside
  • Specification:9.9kg
  • Trademark:XZH TEST
  • Origin:China Xi′an
  • HS Code:9030899090
  • Production Capacity:1000pieces,Year
  • Package size per unit product:465.00cm * 385.00cm * 420.00cm
  • Gross weight per unit product:10.000kg

Description

Overview

Product Description

Product Features

New Design Multiple Pulse Cable Fault Distance Locator

Product Parameters

Product nameUnderground cable fault pre-locator(TDR)
ModelXHGG502
MOQ1 Unit
Main functionFor underground cable fault rough distance measurement
Data sampling rate60MHz, 120 MHz, 240MHz, 400MHz
Test distance>60Km
The test cable length is set<1Km (short distance);<3Km (medium distance);>3Km(long distance)
Pulse amplitude400Vpp
Pulse width0.1uS and 2uS
Reading resolution0.1m
system test accuracyLess than 0.5m
Pulse coupler withstand voltage38kVDC
Working conditionstemperature -25ºC~+55ºC, relative humidity 85%, atmospheric pressure 750±30mmHg.
Measuring methodLow-voltage pulse method, high-voltage flashover method, multiple pulse method
