Environment Hass Testing Equipment in Rapid Thermal
Guangdong Yuanyao Test Equipment Co., Ltd.- Max Diameter of Workpiece:<500mm
- Mass Scope of Workpiece:<900kg
- Type:Material Testing Machine
- Maxcapacity:<1000KN
- Accuracy Grade:1
- Load Way:Electronic Load
Base Info
- Model NO.:YICT-1000
- Loading Method:Dynamic Load
- Display:Digital
- Control:Manual Control
- Weight:100-500Kg
- Power Source:AC110V
- Oil Cylinder Position:Under
- Internal Size(mm):1000*1000*1000
- Circulation:Sirocco Fan
- Insulation:PU&Fiberglass Wool
- Materia:Stainless Steel
- Warranty:12 Months
- Temp.Resolution:0.01 Oc
- Heating System:High Speed Heater
- Cooling:Air Cooling Condenser
- Customization:Inner Chamber Size, Temperature&Humidity
- Temp.Range:-70oc-150oc
- Transport Package:Wooden Cases
- Specification:1000L
- Trademark:Yuan Yao
- Origin:Guangdong, China
- Production Capacity:100 Sets,Month
Description
ºCModelYIT-408 YIT-800 YIT-1000 Internal Dim.W×H×D(mm) 600×850×800 1000×1000×800 YIT-1000 External Dim.W×H×D(mm) 1600×2030×1750 2100×2280×1950 2100×2280×1950 Temp, Range -70 ~ -150ºC(KS); -40 ~ -150ºC(KL); +20 ~ -150ºC(KR) Rapid Changes Temp.Range -70model:-50~+85ºC(KS),-40model:-20~+85ºC(KL),-20model:0~+85ºC(KR) Heating & Cooling Rate 3 ° C / min, 5 ° C / min, 8 ° C / min, 10 ° C / min, 15 ° C / min linear average or nonlinear average Performance Temp. Constancy ±2.0ºC Temp.Uniformity ±1.5ºC Indication Resolution 0.01ºC Heat-at Time -70 ~ -150ºC<60min; -40~ -150ºC<50min; +20~-150ºC<35min Pull-down Time +20~-70ºC<70min; +20~-40ºC<55min; +20~-20ºC<35min Material Exterior Stainless steel plate+powder Coated Interior SUS#304 stainless steel plate Insulation PU & Fiberglass wool Systems Circulation Siroco fan Heating Heater;stainless-gang Fin-type heat pipe heat pipe heating mode of air circulation Cooling Airtight compressor+vaporator fins+air-cooling condenser Other Compenets Vacuum glass inspection window, cable port,control status indicator lights,chamber lamp,
experiment separation shelves(freely adjustable 2pcs) Safety Devices No fuse overload protection, the compressor overheating,over-current, over-pressure,dry heat,
inside the over-temperature warning system Power Source(K.W.) AC 3Ψ 380V 60/50Hz
Product detailes:
Company profile
In addition to water rain spray test chamber, we are also manufacturing:
Precision Oven Tester, Triple Type Temp. & Humi. Chamber, Temp. &Humi. Control Host, Air Thermal Shock Tester, Liquid Thermal Shock Tester, Salt Spray Tester, Walk-in environmental Test Room, Temp. Humi. &Vibration Conbined Test Chamber, Aging Oven Tester, Rain/Spray Test Chamber, Burn-in test equipment, Dust Tester, Steam Aging Tester, Vibration Tester, Tensile Tester, Drop Tester and so on.
Other styles / size with different configurations are available upon request, welcome to enquire and purchase!
If you want to know more about water resisitance test chamber,please feel free to contact us.
Thank you for your reading !
