• Model NO.：KM-F-90A,C
• Heater Power：7kw+0.75kw
• Max. Temp：35oc or 50oc
• Volume：270
• Air Compressor：1,2HP
• Salt Water Temperature：35 ºC ~ 55 ºC
• Settlement：1-2ml , 80cm2 , H
• Inner Material：5mm A Grade PVC Corrosion-Resistant Plate
• Weight：Approx. 135kg
• Transport Package：Strong Plywood Case, Meet International Standards
• Specification：Standard and Customized
• Trademark：KOMEG
• Origin：Dongguan, China
• HS Code：90321000
• Production Capacity：1000 Sets Per Yesr

ModelKM-60CKM-90CKM-120CKM-160CKM-200CInner size (L*W*H cm)60x45x4090x60x50120x80x50160x100x50200x100x60External size(L*W*H cm)110x60x120141x90x120185x105x120235x125x130265x125x140Inside tempBrine test method(NSS ACSS)35°C±1°C/Corrosion resistance test method(CASS)50°C±1°CBrine temp35°C±1°C 50°C±1°CTest chamber volume108L270L480L800L1200LBrine chamber volume15L20L30L40L60LCompressed air pressure1.00±0.01kgf/cm2Spray volume1.0~2.0ml/80cm2/h (Collect at least 16 hours, the average)PH6.5~7.2 3.0~3.2PowerAC220V 50Hz 2.5KWAC220V 50Hz 2.5KWAC220V 50Hz 3.5KWAC380V 50Hz 4.5KWAC380V 50Hz 5.5KW

FAQ

1. Q: Have your machine met relevant standards, and with relevant TEST CERTIFICATE?A: Yes, our machines are manufactured according to International Standards. If TEST CERTIFICATE required, it can be offered.

2. Q: How-to video provided?A: Yes, if required, our engineers will record a specialized how-to video for you.

3. Q: Is the machine-made in your own plant?A: Yes, welcome to visit our plant(factory), also we support OEM and ODM.

4. Q: How you do the maintenance oversea?A: In the way, you are convenient, by Telephone or E-mail or Video meeting, etc.
