Test Instrument

Home > Product > Environmental Test Chamber

Altitude Test Chamber, Pressure Testing Chamber

Dongguan Xin Bao Instrument Co., Ltd.
  • After-sales Service：Online Services and Localization Services
  • Power Supply：220V,50Hz or Can Be Customized
  • Certification：CE, TUV, ISO
  • Warranty：14 Months
  • Transport Package：Standard Export Wood Package
  • Specification：Inner chamber size: 40*50*80cm(WHD)

Base Info

  • Model NO.：XB-OTS-408
  • Trademark：OTS
  • Origin：China, Mainland
  • HS Code：8479899990
  • Production Capacity：238sets,Month

Description

Inner Size (D*W*H)mmCapacity(KW)Chamber Volume(L)SpecificationsTemp range±0.5%Temp deviation≥100ºC, ±3.0ºC(at 101kPa, ATM no load)<100ºC, ±2.0ºC(at 101kPa, ATM no load)Cooling rate0.7ºC~1.0ºC/min (Average)Pressure range101kPa ~1kPaPressure accuracy ±2kPa (101kPa ~ 40kPa),  ±0.5kPa (4kPa~40pKa ),   ±0.1kPa (4kPa~1kPa)Depressurization rate101kPa ~1kPa≤30mins (Room temp)Pressure recovery rate10kPa/Min(adjustable)


Standard configuration:
Two sample holders; an observation window; φ25 or φ50 cable hole.

Optional parts:
Communication interface RS232 or RS485, logger, micro printer, remote temperature and humidity control system (including printers, communications software, computer), mobile casters.

Structure:
Overall structure: the new design is easier to operate and maintain.
Water and electricity system is separated;
External humidifying design;
Three levels of overheat protection, easy access for refrigeration servicing, etc.

Material:
Tecumseh, Bock Compressor;
High quality electronic components

Standards Implemented and Met
B10592-89 Technical requirements for high and low temperature test chamber
GB2423.1-1989 Low temperature test
GB2423.2-1989 High temperature test mode





Altitude Test Chamber, Pressure Testing Chamber






FAQ:
1. Are you a Manufacturer ? Do you offer after-sales service? How can I ask for that? And how about the warranty?

Yes, we are manufacturer of Climatic Test Chamber,Competitive Price Altitude Test Chamber,Pressure Testing Chamber,Pressure Chamber .Every machine from our factory has a 14-month warranty after shipment. Generally, we offer 12 months for the FREE maintenance, while considering of sea transportation, we can extend 2 months for our customers.



If your machine doesn't work, you can send E-mail to us and we will try our best to find the problem by email or skype video chat if neccesary. After confirmation of the problem, we can send you new spare parts or provide on-site repair


2. What's the delivery term?

At most of time, we have stock in the factory. If there is no stock, normally, the delivery time is 15-20 working days after deposit receipt. If you are in urgent need, we can consider making a special arrangement for you.



3. Do you accept customization service? Can I have my logo on the machine?

Yes, of course. We can not only offer standard machines, but also customized

machines according to your requirements. And we can also put your logo on the machine


4. How to install and use the product?

We will send you operating instructions, English  video by Email. Or you can download on our officail website directly.

Most of our machine is shipped with a whole part, which means it is already installed, all you need to do is to connect the power cable and start to use.  And if possible, we can also install your machine at site.
