Eddy Current Conductivity Meter Digital Metal Conductivity Tester
EP HIPOT ELECTRIC CO., LTD.- After-sales Service：Remote Guidance
- Warranty：1or 2 Years Free Warranty Longlife Service
- Max Diameter of Workpiece：<500mm
- Mass Scope of Workpiece：<900kg
- Type：Universal Testing Machine
- Accuracy Grade：0.01
Base Info
- Model NO.：EPCH-2008 Series
- Load Way：Electronic Load
- Display：Digital
- Control：Computer Control
- Weight：0-100Kg
- Power Source：Battery
- Working Freq.：60kHz, Sine Wave
- Measurement Range for Conductivity：0.51 %Iacs to 112 %Iacs, or 0.3 Ms,M to 65 Ms,M, O
- Resolving Power：0.01%Iacs(When<51%Iacs)
- Measuring Precision：+-1%
- Lift-off Effect：Probe Compensation 500μm
- Application Area：Conductivity and Resistivity Measurement of Non-
- Application：Determining Extent of Thermal Treatment
- Checking：Thermal Damage, Material Fatigue and Crack
- Determining：Metal Purity
- Monitoring：Metal Homogeneity
- Dimension of Host Machine：220mmx95mmx55mm
- Weight of Host Machine：0.5kg (Including Batteries)
- Shell of Instrument：Engineering Plastic, High Impact-Resistance, Water
- Communication with PC Machine：RS 232 Interface
- Reading Memory：Storage for 500 Groups of Measured Data Files.
- Transport Package：Carton or Playwood Case
- Specification：220mmx95mmx55mm
- Trademark：EP Hipot Electric
- Origin：Wuhan, China
- HS Code：9030390000
- Production Capacity：1000,Year
Description
±1% of measurements
2008C1
1. Measurement range:
The measurement range of model A, B, B1 or C is large. Besides copper, copper alloy, aluminum and aluminum alloy, the instrument can also measure titanium, titanium alloy and other low conductivity non-ferrous metal. You needn't separately buy high or low conductivity instrument, but one our instrument is enough.
2. Lift-off compensation
Lift-off compensation is a important parameter of eddy current conductivity meter, which means the instrument's capacity for overcoming the non-conductive layer (as paint, coating, etc.) above the tested material. Model A, A1, B or B1 is the same as foreign same type instrument. Even if there are coating, paint, or other impurity and rough surface above the tested material, you could get the accurate testing data only if the gap is less than 0.5mm.
3. Working frequency
The currently used working frequencies are 60 KHz and 500 KHz, 60 KHz for aviation industry standard, 500 KHz for detecting sheet metal. Model B is the only instrument, which has a high and a low frequency probes and the high frequency probe is up to 500 KHz. The high frequency probe can be used for too thin workpiece whose thickness is 0.1mm to 0.3mm, so you no longer have to worry about measuring too thin workpieces.
4. Measurement area
The diameter of eddy current conductivity meter's probe is usually between 13mm and 14mm, but model B has a big probe and a small probe whose diameter is 8mm. The probe is used of electromagnetic shielding technology, that the measured material needn't be more than twice the size of probe. It can measure the small workpiece with the minimum value of 8mm, so you no longer have to worry about measuring too small workpieces.
5. Measuring camber and rapid sorting
Model B has unique camber modification technology, with the special camber measurement mode and "∧" shape probe cover, the camber material can be measured stably.
Model B has continuity measurement function, which can help you sort materials quickly by setting the upper and lower bound warning, in order to maximize efficiency
6. Temperature compensation
Model B used the advanced technology, which has the real full-automatic temperature compensation. Even if the block's temperature is different with the material, it could automatically compensate the standard values.
7. Data storage
All models can save 500 sets date. It can be set as auto-saving without affecting the operating speed. You no longer have to take notes but easily view the measurements at any time, that also reduce manual error rate. All models except C of EPCH series' instruments can connect the computer and upload data to the computer to organize and print
8. Measurement accuracy
Each model's indicators and functions are different from the other, but the most critical parameter called measurement accuracy of instrument is uncompromising. All models' accuracy is up to ±0.5% ~ ±1% as the foreign same type instrument, to ensure the most precise measurements.
9. Measurement parameter
All models have three kinds of measurement parameters are "MS/m", "%IACS" and "Ω• mm²/m", one keyboard toggle without manual handling, be wonderfully easy to use.
This series can be customized according the customer's requirements. More details on EPCH-2008 Series Eddy Current Conductivity Meter Digital Metal Conductivity Tester please contact EP Hipot Electric, we have professional tech team to design correctly designed products and systems.
