ASTM D4308 Aviation and Distillate Conductivity Tester for Liquid Hydrocarbons
Chongqing Advanced Technology Co., Ltd.- After-sales Service:Response in 12 Hours
- Warranty:1 Year
- Test Standard:ASTM D2624,ASTM D4308,ISO 6297
- Measuring Range:1~19999PS,M
- Accuracy of Conductivity Cell:1.00,M±5%
- Overall Dimention:φ100×35mm
Base Info
- Model NO.:CM-08B
- Weight:0.5kg
- Display:LCD
- Dimension of Electrode:φ14×140mm
- Test Sample:General Oils,Lubricating Oil,Aviation Fuel
- Power Supply:in-Built 6f22 Type 9V Battery
- Function:Determine Conductivity of Light Petroleum
- Color:White
- Stock:Available
- Price:Low
- Transport Package:Plywood Case
- Specification:Small
- Trademark:AI
- Origin:China
- HS Code:9031809090
- Production Capacity:50 Sets,Month
Description
Basic Info.
Model NO. CM-08B Weight 0.5kg Display LCD Dimension of Electrode φ14×140mm Test Sample General Oils,Lubricating Oil,Aviation Fuel Power Supply in-Built 6f22 Type 9V Battery Function Determine Conductivity of Light Petroleum Color White Stock Available Price Low Transport Package Plywood Case Specification Small Trademark AI Origin China HS Code 9031809090 Production Capacity 50 Sets/MonthProduct Description
Introduction
This electrical conductivity meter is mainly used to determine conductivity of light petroleum,such as gasoline,kerosene and diesel etc.
This electrical conductivity meter is mainly used to determine conductivity of compressor oil,lubricating oil. By measuring conductivity,we can qualitatively know the Electrostatic safety,insulating performance,purity and other physical characteristics rapidly.
Reference standards:
- ASTM D4308-89
- ASTM D2624
- ISO 6297
- GB 6950-2001
- GB/T 6539-1997
- GB 13348-1992
Technical specifications
1.Measuring range:
Model | Measuring range and resolution | Conductivity measuring value and accuracy | Main application |
CM-08B electrical conductivity meter | 1~19999pS/m±1pS/m | 1~19999pS±(2%+2pS) | General oils,lubricating oil |
CM-08C electrical conductivity meter | 0.1~1999.9nS/m±0.1nS/m | 0.1~1999.9nS±(2%+2d) | Alcohol, acetone, isopropanol |
(pS/m is unit of conductivity,equivalent to 'cu');
2.Structural constant and accuracy of conductivity cell:1.00/m±5%;
3.Reading mode:LCD digital display;
4.Power supply: in-built 6F22 type 9V battery,intermittently power supplying.(for exporting,the battery need to prepare by users);
5.Working condition: Temperature: 0~+40ºC; Relative humidity:≤85%
6.Structure characteristics:
Half-sealed structure
iaAT5 design
Small and portable
7.Overall dimension:
Main unit:φ100×35mm
Electrode:φ14×140mm
8.Weight:0.5KG
Factory overviewCustomer Feedback
Germany
USA
Package
FAQ
1.What's the delivery time?
About 10 days.
2.What's your payment terms?
30% paid by T/T in advance,70% paid by by T/T before shipping.
3.What's your guarantee terms?
The warranty of all products is 1 year.During this period,we are responsible for all faults caused by us.And we can supply life-long technical support.
4.Can you supply training?
We can supply training in our factory and online training for free.If onsite installation and training are required,please pay for tickets,accommodation and salary USD150/Day for every person.
