ASTM D2170 High Temperature Kinematic Viscosity Bath for Asphalt and Bitumen

Chongqing Advanced Technology Co., Ltd.
  • After-sales Service：Response in 12 Hours
  • Warranty：1 Year
  • Test Standard：ASTM D2170
  • Power Supply：AC(220±10%)V,50Hz
  • Heating Power：1700W
  • Temperature Control Accuracy：±0.1ºC

Base Info

  • Model NO.：KV-H
  • Temperature Range：Ambient to 180ºC
  • Dimension：530mm×400mm×670mm
  • Display：LCD
  • Color：White
  • Total Power Consumption：1800W
  • Working Position：3
  • Bath Capacity：About 23L
  • Application：Asphalt Testing
  • Function：Determine The Viscosity of Asphalt at High Temp.
  • Test Method：Capillary Viscometer
  • Diameter of Capillary：1.02, 1.26, 1.48, 1.88, 2.20, 3.10 and 4.00 mm
  • Transport Package：Plywood Case
  • Specification：Automatic
  • Trademark：AI
  • Origin：China
  • HS Code：9031809090
  • Production Capacity：20 Sets,Month

Description

1Power supplyAC(220±10%)V, 50Hz2Heating power1700W3Temperature rangeAmbient to 180ºC4Temperature control accuracy±0.1ºC5Mercury-in-glass thermometerScale division 0.1ºC6Bath capacityabout 23 L7Working postionYou can make determination using 3 capillary viscometers at a time.8Stirring motor  (1) Power: 6W  (2) Speed: 1200 RPM9Ambient temperature-10ºC~+35ºC10Relative humidity<85%11Temperature sensorRTD, Pt10012Maximum power consumption1800 W13Capillary viscometerOne group of Cannon-Fenske Opaque capillary viscometers; 7 pieces in total. They are No.200, 300, 350, 400,450, 500 and 600 (The inner diameters of R tube of them are 1.02, 1.26, 1.48, 1.88, 2.20, 3.10 and 4.00 mm respectively).14Overall dimension530mm×400mm×670mm(Bath is included)




Factory overview

ASTM D2170 High Temperature Kinematic Viscosity Bath for Asphalt and Bitumen
Customer Feedback

Germany
ASTM D2170 High Temperature Kinematic Viscosity Bath for Asphalt and Bitumen
USA
ASTM D2170 High Temperature Kinematic Viscosity Bath for Asphalt and Bitumen
Package
ASTM D2170 High Temperature Kinematic Viscosity Bath for Asphalt and Bitumen
FAQ
1.What's the delivery time?
About 15 days.

2.What's your payment terms?
30% paid by T/T in advance,70% paid by by T/T before shipping.

3.What's your guarantee terms?
The warranty of all products is 1 year.During this period,we are responsible for all faults caused by us.And we can supply life-long technical support.

4.Can you supply training?
We can supply training in our factory and online training for free.If onsite installation and training are required,please pay for tickets,accommodation and salary USD150/Day for every person.
