• Model NO.：ZNCF220-20
• Brand：Triumph Load
• Nominal Voltage：DC 220V
• Charge Voltage：90-275V
• Charge Current：2-20A
• Discharge Voltage：DC220V±10%
• Discharge Current：1-20A
• Charge Discharge Capacity：10-200ah
• Discharge Time：1m---99h59m
• Accuracy：Current--0.1A, Voltage --0.1V
• Working Voltage：AC Single Phase 220V,50Hz
• Transport Package：Plywood Wood Case
• Specification：ZNCF220-20
• Trademark：triumph load
• Origin：China
• HS Code：9030339000
• Production Capacity：10000set,Year

Basic Info.

Model NO. ZNCF220-20 Brand Triumph Load Nominal Voltage DC 220V Charge Voltage 90-275V Charge Current 2-20A Discharge Voltage DC220V±10% Discharge Current 1-20A Charge Discharge Capacity 10-200ah Discharge Time 1m---99h59m Accuracy Current--0.1A, Voltage --0.1V Working Voltage AC Single Phase 220V/50Hz Transport Package Plywood Wood Case Specification ZNCF220-20 Trademark triumph load Origin China HS Code 9030339000 Production Capacity 10000set/Year

Product Description

Intelligent DC 220V Battery Charger Discharger
 1.Intelligent DC 220V Battery Charger Discharger Introduction
This machine has integrated the function of charging, discharging and activation, which can provide comprehensive and scientific testing means for storage batteries and UPS.
 2.Intelligent DC 220V Battery Charger Discharger Main Features
1).Charger combined with discharger together.
2).Intelligent three-phase charging,constant-current discharging.
3).LCD display,English menu prompt,and the operation is easy and intellectualiz-ed.
4).Real-time online monitoring function:Real-time online monitoring,all test data are displayed:Current,battery pack
voltage,time,capacity and temperature etc.
5).Automatic discharging charging function:Set high/low limit of discharging/charg-ing current,length of time,
capacity and voltage,the discharging/charging process can be cycled once.
6).Automatic stopping function:Automatically stop discharging/charging when meet any of the following conditions:Time out,capacity or battery pack protecting voltage reached preset value.
7).The alarm and protection function:There will be alarm prompt when the voltage is abnormal or temperature is
high.
8).Calibration and correction function of voltage and current display value:Mainly calibrate the total voltage and current of the battery pack.
9).Has function of RS232 interface communication and U disk upload.
 3.Intelligent DC 220V Battery Charger Discharger Technical Parameter

Nominal voltage	DC220V
Charge voltage	90-275V
Charge current	2-20A
Discharge voltage	DC220V±10%
Discharge current	1-20A
Charge/discharge time	1M-99H59M
Charge/discharge Capacity	10-200Ah
Current accuracy	0.1A
Control precision	1%
Accuracy of measurement	1%
Adjust fineness	1A
Working power	AC220V,50Hz
Dimension	340*720*580mm
Cooling	Forced air cooling

4.Why choosing us
The earliest and most professional manufacturer of AC/DC Load Bank in China, dedicated to this industry for more than 20 years.
The most patent technology and scientific research awards gainer in China.
Advanced detection method and strict inspection procedure build the qualified quality.
Customized production meet the individual requirement.
Prompt delivery & excellent after sales service.
Cooperate with many well-known enterprise, offer OEM and ODM service to world famous brands.
Certified with China Classification Society (CCS) and ISO9001:2008 Quality Certificate.
Triumph Load is the first brand in the emergency power supply test & maintenance industry in China.
