• Model NO.：KOV-400A-4
• Accessories：Timer, Adjustable Compartment Plate
• Safety Devices：NFB, Over Temp. Reley, Fuse
• Temp. Range：50oc~200oc or 300oc
• Temp. Constancy：+,-1.0oc
• Temp. Uniformity：+,-2.0oc(50oc~200oc), +,-3.0oc(50oc~300oc)
• Heat up Time：50oc~200oc Within 5 Mins
• Insulation Material：Glass Wool
• Transport Package：Strong Plywood Case, Meet International Standard
• Specification：Standard and Customized
• Trademark：KOMEG
• Origin：Dongguan, China
• HS Code：90321000
• Production Capacity：1000 Sets Per Yesr

Basic Info.

Model NO. KOV-400A-4 Accessories Timer, Adjustable Compartment Plate Safety Devices NFB, Over Temp. Reley, Fuse Temp. Range 50oc~200oc or 300oc Temp. Constancy +/-1.0oc Temp. Uniformity +/-2.0oc(50oc~200oc), +/-3.0oc(50oc~300oc) Heat up Time 50oc~200oc Within 5 Mins Insulation Material Glass Wool Transport Package Strong Plywood Case, Meet International Standard Specification Standard and Customized Trademark KOMEG Origin Dongguan, China HS Code 90321000 Production Capacity 1000 Sets Per Yesr

Product Description

Precision Multilayer High Temperature 200 Degree Drying Aging Oven for PCB Product

Description

Precision Oven is applied tothe industrial and mining enterprises, laboratories, research units for drying, baking, melting and sterilization test. And used to test its performance in the case of high temperature, thermostat change, such as electrician electronics, automobile and motorcycle, ship, universities, scientific research institutes and other related products, parts and materials.
Volume and dimension

2.1  Volume	About 360 Liter
2.2  Interior size	W 1000 mm*H 600 mm*D 600 mm
2.3  Exterior size	W2790 mm*H1745 mm*D1450 mm (Excluding the protruding part of the machine!) Tips: For external dimensions, please confirm the three views according to the final design!
2.4  Floor area	About 4.05 m2; (confirm after signing the contract)

3.1  Test Conditions	Cool method: fresh air Measured at a room temperature of +25 ºC under no load, the temperature and humidity performance test is measured according to the relevant regulations according to IEC 60068 -3; the sensor is placed at the air outlet of the air handling unit
3.2 Temperature range	RT+10ºC~+200ºC
3.3Temp.  fluctuation	±0.5ºC
3.4Temp.  uniformity	±2.0ºC (RT ~ +100ºC) ±3.0ºC (101 ~ +200ºC)
3.5 Heat up rate	RT+10ºC ~ 200ºC   ≤65min  (no load)
3.6 Load	No
	Note: Measured at room temperature +25 °C at no load, the temperature and humidity performance test is measured according to the relevant regulations according to IEC60068 -3; the sensor is placed at the air outlet of the air handling unit
3.8 Noise	<=75 (dB) (The noise detection device is measured 1m away from the door of the chamber)
3.9 Meet standard	GB/T 2423.2-89 (IEC68-2-2) Test B: High temperature test method GJB360.8-87 (MIL-STD.202F) High temperature life test GJBl50.3 (MIL-STD-810D) High temperature test method

After-sale service

If you face any problems in the future during the testing process we promise we will give you a reply within 48 hours and the solution provide within 3 working days. We can offer operation video and English operation muanual. We can provide video-conference. If customers require on-site service, the transport and travel expense shall be borne by the customer.
