• Model NO.：SH-160
• Compressed Air Pressure：1.0~6.0 (Kgf)
• Standard：IEC, ASTM B117
• Transport Package：Plywood Case
• Specification：CE, ISO
• Trademark：ASLi
• Origin：Guangdong, China
• HS Code：85141090
• Production Capacity：30 Sets,Month

Salt Spray Test Chamber Technical Parameters ModelSH-90SH-120SH-160SH-200Internal Dimension
W*H*D (mm)900*600*5001200*800*5001600*800*5002000*1000*500External Dimension
 W*H*D (mm)1400*950*12001900*1300*14002300*1300*14002700*1500*1500Lab TemperatureSaline test (NSS ACSS)   35±1 degree C  ;Corrosion Test (CASS)50±1 degree CPressure Bucket
TemperatureSaline test method (NSS ACSS) 47±1 degree C / Corrosion Test (CASS)63±1 degree CLab Capacity(L)2705008001500Saline Capacity(L)25404040Saline Concentration5% concentration of NaCl, or every Liter 5%  NaCl add 0.26g CuCl2H2OCompressed Air
Pressure(Kgf)1.0~6.0 Spray Volume1.0~2.0ml /80cm2 /h(working at least 16 hours, and take the average value)Spray Form Continuous Spraying or Programmable SprayingPowerAC220V 1phase  3 lines15A Weight(Kg)6580120160200

Salt Spray Test Chamber Features:
1. Adopt automatically or manually adding water system, can watered by itself while lack of water.
2. Precise glass spray nozzle, good uniformity, mist dropping naturally, no NaCl crystallized salt
3. Double over-heat protection devise and alarm when water short storage to ensure use safety.
4. Digitally temperature controller, PID controlled, precision of ±0.1ºC
5. Laboratory direct steam-heated, even heating speed, reducing the standby time.
6. Tapered Spray tower, even mist dropping
7. Saturated bucket is SUS #304, convenient for heating and humidifying, offer humidity for testing
8. Concentration of NaCl: 5%; PH of the water: 6.5-7.2 (Liquid)

IEC Standard Sea Salt Spray Corrosion Test Chamber Pictures:


Warranty: one year free warranty for whole set machine,lifelong time maintainance.

After-sale service: feedback within 8 hours after get the call or email.

Service:OEM service,Design service,Buyer lable service.
