• Model NO.：DA-II
• Receiving Cylinder：100ml
• Distillation Flask：125ml
• Dimension：760mm×520mm×500mm
• Net Weight：40kg
• Display：LED
• Operation：Manual
• Working Position：Two Units
• Color：White
• Price：Low
• OEM Service：Available
• Transport Package：Plywood Case
• Specification：Small
• Trademark：AI
• Origin：China
• HS Code：9031809090
• Production Capacity：20 Sets,Month

Basic Info.

Model NO. DA-II Receiving Cylinder 100ml Distillation Flask 125ml Dimension 760mm×520mm×500mm Net Weight 40kg Display LED Operation Manual Working Position Two Units Color White Price Low OEM Service Available Transport Package Plywood Case Specification Small Trademark AI Origin China HS Code 9031809090 Production Capacity 20 Sets/Month

Product Description

Summary
  This Distillation Characteristics Measuring Equipment is designed and made as per standards GB/T6536 Test Method for Distillation Characteristics of Petroleum Products and ASTM D86 Standard Test Method of Distillation for Petroleum Products at Atmospheric Pressure. It is suitable to determine the distillation characteristics of gasoline, aviation gasoline, jet fuels, solvent having special boiling point, naphtha, diesel oil, distillate fuels, and other petroleum products.
   This Distillation Characteristics Measuring Equipment is not only suitable to the organizations of high frequency with various of samples but also accelerate the test speed for common users. It is an ideal distillation tester for petroleum products.

I. Main technical features
1.The Distillation Characteristics Measuring Equipment adopts double units working mode, can do test for one sample as well as two samples which having the same specification or different specifications.It highly improves the work efficiency.
2.It adopts two groups of independent digital temperature controller, heater, electric stirrer to constitute two constant temperature baths. Each bath temperature can be adjusted and controlled independently.The temperature in the bath is uniform,can fully meet the requirements of test.
3.The Distillation Characteristics Measuring Equipment adopts special heating furnace to ensure the safety of test. Heating power can be continuously adjusted to meet the requirements of test.

II. Main technical specifications
1. Power supply: AC(220±10%)V, 50Hz
2. Total power consumption:≤4000W
3. Receiving cylinder: 100ml, division value 1ml.
4. Distillation flask: 125ml,meet the requirements of GB/T 6536 and ASTM D86
5. Thermometer: (-2~300)ºC and (-2~400)ºC, division value 1ºC
6. Flask support board: Sic, bore diameter φ32mm, φ38mm, φ50mm.
7. Temperature controller:
     (1) Range:(Ambient +10)ºC~60ºC
     (2) Accuracy: ±0.5ºC
     (3) Display: LED
8. Ambient temperature: 15ºC~35ºC
  Relative humidity: ≤85%
9. Dimension:760mm×520mm×500mm
10. Net weight:40kg.


Factory overview

Customer Feedback

Germany

USA

Package

FAQ
1.What's the delivery time?
About 15 days.

2.What's your payment terms?
30% paid by T/T in advance,70% paid by by T/T before shipping.

3.What's your guarantee terms?
The warranty of all products is 1 year.During this period,we are responsible for all faults caused by us.And we can supply life-long technical support.

4.Can you supply training?
We can supply training in our factory and online training for free.If onsite installation and training are required,please pay for tickets,accommodation and salary USD150/Day for every person.
