Test Instrument

Home > Product > Other Test Instrument

Water Spray Test Chamber/ Rain Spray Test Chamber

Sailham Equipment (Dongguan) Co., Ltd.
  • Certification：Ce, RoHS, FCC, ISO, SGS Certificates
  • Internal Dimension (mm)：W1000 * H1000 * D1000 Customized
  • IP Degree：Ipx3, Ipx4 or Other IP1~8
  • Service Type：OEM , ODM , Non-Standard Available
  • Application：School, Hospital, Lab, Factory
  • Power Supply：AC220V,AC380V, Customized

Base Info

  • Model NO.：ZH-LY-1000
  • Rotating Speed：1 ~5rpm,Min, Adjustable
  • Water Pipe Diameter：φ16mm
  • Inner Material：SUS304 Stailess Steel
  • Meet The Standard：IEC60529, GB4208-2008, GB7000.1
  • Transport Package：Wooden Case
  • Specification：Customization available
  • Trademark：Sailham
  • Origin：Guangdong, China
  • HS Code：8479899990
  • Production Capacity：5000sets,Year

Description

Model NoZH-LY-600ZH-LY-800ZH-LY-1000Volume 500L1000LInternal dimension (mm)W600 * H600 * D600W800 * H800 * D800W1000 * H1000 * D1000External  dimension (mm)W1200 * H1450 * D850W1400 * H1650 * D950W1600 * H1850 * D1150IP degreeIPX3, IPX4 or other IP1~8Sample shelf sizeφ400mmTest box rotating speed1 ~5rpm/min , adjustableSpray orifice diameterφ0.4mmWater pipe diameterφ16mmTest box materialHigh quality 304 stainless steel mesh plateSpray ring radius375 and 500mmSwing pipe±45°,±60°,±90°,±180°(theory number)Swing pipe swing1-300° (adjustable) stepper motor controlSwing pipe materialHigh quality 304 stainless steel seamless pipeMeet the standardIEC60529:1989+A1:1999,GB4208-2008,GB7000.1(IPX3,IPX4)
Water Spray Test Chamber/ Rain Spray Test Chamber

Sailham Customer
Water Spray Test Chamber/ Rain Spray Test Chamber
Certifications
Water Spray Test Chamber/ Rain Spray Test Chamber
FAQ
Why choose us?
1. Consider different countries plugs, manually change the-voltage from 110V to 220V, as insurance indicator.

2.Excellent After sale Service:
12 months warranty. Besides, we can help you to repair your equipment for free, even it's not from our factory. What can we do for you, just don't hesitant to contact us.

3.Commitment:
We will sign a letter of commitment while we sign the contract, which will improve your confidence to us.

4.Good Packaging:
Simulation Animatronic Customer Triceratops are covered with air bubble film before put them into the wooden case, which not only has good shock absorption, impact resistance, heat sealing and also has the advantages of nontoxic, odorless, moisture corrosion, good transparency etc.
