Test Instrument

Lab High Temperature Aging Testing Accelerated Equipment

GUANGDONG BELL EXPERIMENT EQUIPMENT CO., LTD.
  • After-sales Service:24 Hours Online
  • Power Supply:380V
  • Certification:CE, ISO
  • Warranty:1 Year
  • Temp.Range:Rt-250ºC (Optional up to 500ºC)
  • Temp. Fluctuation:≤±0.5ºC

Base Info

  • Model NO.:BTG-SERIES
  • Temp. Deviation:≤±1.5ºC
  • Display:TFT LCD
  • Input:Compatible for Wet-Dry Bulbs PT100(T,C,Rtd,Dcv)
  • Transport Package:Each Set Protected with Resin Fiber and PP Film, T
  • Specification:450x400x400(customizable)
  • Trademark:DGBELL
  • Origin:Guangdong China
  • HS Code:8514109000
  • Production Capacity:100set ,Month

Description

ModelBTG-072BTG-125BTG-270BTG-270BTG-1000Test Space
W x H x D (mm)450x400x400450x400x400900x1100x10001000x1000x6001000x1000x1000External Dimension
W x H x D (mm)850x1000x850900x1100x10001000x1300x10001200x1450x11001200x1400x1450
Performance parameters:Temp. RangeRt-250ºC (Optional for 500ºC)Temp. Fluctuation ≤±0.5ºCTemp. Deviation≤±1.5ºCTemp. Uniformity≤±1ºC
Controller:DisplayTFT LCDInputCompatible for wet-dry bulbs PT100(T/C,RTD,DCV)Accuracy0.01% high precision samplingSystem Capacity10 programs , 100 segments for each programOperating ModeFixed value/ Programmable running modeOutput MethodPID+SSR/SCR automatic bidirectional synchronous outputStart pre-setEquipment starting can be pre-set.Communication InterfaceCompatible for protocols (RS485,Modbus etc.)Lab High Temperature Aging Testing Accelerated EquipmentLab High Temperature Aging Testing Accelerated Equipment

Established in 2005, Guangdong Bell Experiment Equipment Co., Ltd is specialized in manufacturing a variety of quality inspection instruments, testing equipments and other high-tech products which mainly include: Constant Temperature & Humidity Test Chamber,High & Low Temperature Test Chamber, High & low Temperature Testers with Rapid Temperature Change, Walk-In humidity & temperature test chamber, Cool/Thermal shock test chamber, Salt spray chamber, High temperature aging tester, sand and dust testing machine,tension tester, high and low temperature testing machine , servo computer battery crush tester, mechanical vibration testerBattery washing tester ,battery burning tester and other quality testing instruments. Thanks to several decades of R&D efforts,the company has established itself as a leading provider of testing instruments of the industry, playing a crucial role in the research and development of high-quality and high-value products within the industry.

15+ years experience in test chambers manufacturing, High performance for your projects.

With unmatched quality advantage, a dynamic management team, professional customer services, superb manufacturing techniques and innovative research and development ideas, Guangdong Bell Experiment Equipment Co., Ltd, supported by an international, standard and professional quality policy, is gradually becoming an international brand. Its products are manufactured in consistent with a number of world standards.
