• Model NO.：XB-OTS-P800
• Dust Concentration：2~4kg,M3
• Test Time：0~999.9hr
• Test Dust：Dry Talcum Powder
• Inner Material：SUS #304
• Transport Package：Standard Strong Wood Case
• Specification：W*H*D800*800*800mm
• Trademark：OTS
• Origin：Guangdong, China (Mainland)
• HS Code：9031809090
• Production Capacity：128 Set,Month

Sand and dust test chambermodelXB-OTS-500PXB-OTS-800PXB-OTS-1000PXB-OTS-1500Pworkroom size(D×W×H)mm800×800×800800×1000×10001000×1000×10001000×1500×1000technical index and materialinnerSUS import stainless steel plateshellcooling steel plate,surface sprayelectrical control systemsPLC Controlertemperature controlTouch- temperature controllerBlower Time1S-99H(optional)Vibration time1S-99H(optional)timing range0-99HDust dosage2-4kg/m³Dust dimensions<=32µm33%.32µm-250µm67%Mesh Diameter50umWire Spacing75ummode of operationProceduredehumidifyelectric heatingTemperature range25ºC-40ºCfairleadΦ50mm. With sealing pluginspection window(mm)visible glass window with scraperthe time of lighting and energizeAdjustable opening and closingpumping time≤60 times ,Gas volume inner of Hull/hourpressure differential≤2kPa(20mbar)blowing machinestainless centrifugal fanvacuum systempressure gauge,air filter regulator,triple pieces of Voltage,connecting pipeElectric componentscontactor, switch and button  import from France Schneider and FULI" japanElectric socketdust-protected socket,16A 220VStandards AppliedGB4208-93 method of dust proof experiment ;method of dust proof experimen;
GB2423.37-89 basic environmental test of electronic product for clectrician  LA. Free-falling dust;
Satisfy rank of protection: IP5X .IP6X  Specific parameters stander by this specification . Electronic and Control systems:
1. The main controller LCD touch screen, can do programmable test
2. PLC complex man-machine interface control, contrived moving time, rest time and power-on time setting.
3. multiple sets of test procedures can be planned in the interface, and each group can be arbitrarily set the desired action, easy to operate.
4. If a fault occurs in the operation of various signals are written records will be displayed to facilitate maintenance.
5. Touch the setting, digital direct display, all the conditions fully automatic locking by a microcomputer.
6. imported electronic temperature and humidity sensor, not need to cleanup.

About Us


Certificate:

Global safety design, use our chambers safely and with peace of mind for many years to come.

We deliver chambers that conform to international safety standards.

Our chambers conform to ISO risk assessment as well as global safety design electrical safety standards such as CE marking and EMC directive.

Packing & Shipping

Packaging Details:Strong wooden case

Delivery Detail: 35 days after getting the payment

Our Services:

We are here to help you. Services available:

Replacement manuals

• Consumables and replacement parts
• On-site maintenance and repair
• Warranty support
• Over-the-phone service support and advice

If you have an OTS chamber  , we will do our best to help you in whatever way we can.

 Manuals: PDF files of manuals for current models are available free. Please contact us to request a copy. Older and printed copies at additional charge.

• Service repair:  We prefer you contact us direct at the factory with any problems you may be experiencing.  We help diagnose the problem, arrange for any needed parts, and schedule a technician to do the repairs.  Rarely can a local contractor get all that done for you as quickly as we can.  We also guarantee the work .

FAQ:

Q1 :  Can you customize the product?

   A:   Yes, we can customize any products according to requirements.

Q2 :  How to choose the most suitable products?

   A:   Our professional team will give you the best suggestion,just be  patiently to tell us the information about the parameters your required.

 Q3 :  Can you arrange installations and commissioning in our lab?

   A:   Firstly, for standard chamber we had 3-5 days commissioning before shipping , you just need link power in your lab, then can start to operate

     Secondly; we had detailed operation manual with chamber , any problems you can find and solve in it
      Thirdly, some of customized chambers we should to install and teach your team to operate .
