• Model NO.：EPT401
• Weight：5.5kg
• Power Source：220V 50Hz or Customized
• Titration Method：Electric Titration (Coulomb Analysis)
• Electrolysis Current Control：0-400mA Automatic Control
• Measurement Range：0ug-200mg
• Sensitive Valve：0.1ug H2O
• Printer：Micro Thermal Printer
• Power：<40W
• Working Environment Temperature：5-40 Degree
• Operating Environment Humidity：Less Than 85
• Overall Dimensions：340*295*155mm
• Calculation Formulas.：4
• Calendar Clock：Have
• History Record：Have
• Analysing：Karl Fischer Titrator
• Transport Package：Plywood
• Specification：340*295*155mm
• Trademark：EP Hipot Electric
• Origin：Wuhan, China
• HS Code：9027809900
• Production Capacity：1000,Year

Basic Info.

Model NO. EPT401 Weight 5.5kg Power Source 220V 50Hz or Customized Titration Method Electric Titration (Coulomb Analysis) Electrolysis Current Control 0-400mA Automatic Control Measurement Range 0ug-200mg Sensitive Valve 0.1ug H2O Printer Micro Thermal Printer Power <40W Working Environment Temperature 5-40 Degree Operating Environment Humidity Less Than 85 Overall Dimensions 340*295*155mm Calculation Formulas. 4 Calendar Clock Have History Record Have Analysing Karl Fischer Titrator Transport Package Plywood Specification 340*295*155mm Trademark EP Hipot Electric Origin Wuhan, China HS Code 9027809900 Production Capacity 1000/Year

Product Description

Transformer Oil Water Content Tester Karl Fischer Moisture Analyzer


General Information:
Karl-Fisher Coulomb titration is the most reliable method for the determination of trace moisture in different substances. EPT401 trace moisture analyzer successfully applied this method, using the most advanced automatic control circuit, 32-bit embedded microprocessor as the main control core, embedded in a mini operating system. This makes the instrument more reliable and easier to use. It has the characteristics of fast analysis speed, simple operation, high precision and strong automation. Widely used in petroleum, chemical, power, railway, pesticide, medicine, environmental protection and other departments.


Features:

• Using 32-bit embedded microprocessor as the main control core, embedded mini operating system.
• 0-400mA automatic detection, high accuracy, fast measurement speed, stable and reliable.
• The main board uses high-quality SMD components, high integration, simple operation and long life
• Contains 4 calculation formulas, the measurement results are automatically converted to the required units, and can be converted to each other.
• Color touch screen, full digital keyboard, simpler operation, convenient and quick data calculation.
• The data can be stored up to 1000 groups, and the name of the operator can be set to facilitate searching, and the reminder of reagent failure is more user-friendly.

Technical Specifications:

Titration method:	Coulometric titration (coulomb analysis)
Display	Color touch screen
Electrolysis current control:	0~400mA automatic control
Measuring range:	1ug~200mg
Sensitive valve:	0.1µg H2O
Accuracy:	10µg~1000µg±3µg Not more than 0.3% above 1mg
Printer:	Built-in thermal printer
Power source:	220V±10%, 50Hz
Work rate:	<40W
Use environment temperature:	5~40ºC
Use environment humidity:	≤ 85%
Dimensions:	(width) 340mm × (depth) 295mm × (height) 155mm
Weight:	about 5.5kg

More details on Oil Tester please contact EPHipot Electric, we have professional tech team to design correctly designed products and systems.
