Flame Aas Atomic Absorption Spectrophotometer with Graphite Furnace

Chongqing Advanced Technology Co., Ltd.
  • After-sales Service：Response in 12 Hours
  • Warranty：1 Year
  • Test Method：Atomic Absorption Spectrometry Aas
  • Wavelength Range：190 ~ 900nm
  • Wavelength Accuracy：±0.15nm
  • Lamp Turrets：8 PCS

Base Info

  • Model NO.：4530F
  • Spectrum Bandwidth：0.1nm, 0.2nm, 0.4nm, 1.0nm and 2.0nm
  • Operation：Controlled by PC
  • Power Supply：AC220V±10%,50Hz
  • Wavelength Acceptance Rate：≤0.04nm
  • Baseline Stability：≤0.002A,30min (Cu)
  • Light Stand：Eight Lights
  • The Highest Temperature：3000c
  • Weight of Flame Aas：75kg
  • Weighg of Furnace：65kg
  • Color：White
  • Acetylene Air Burner：100mm
  • Transport Package：Hardboard
  • Specification：Small
  • Trademark：AI
  • Origin：China
  • HS Code：9031809090
  • Production Capacity：20 Sets,Month

Description

Wavelength range190 ~ 900nmSpectral bandwidthCan automatically change between 0.1nm, 0.2nm, 0.4nm, 1.0nm and 2.0nmAccuracy of the wavelength±0.15nmReceptivity of the wavelength≤0.04nmBase line stability≤0.002A/30min (Cu)Characteristic viscosity0.02μg/ml/1% (Cu)Checking limit0.004μg/ml (Cu)Preciseness0.5%Grating1800 lines/mmInflamerAll-metal titanium burnerAtomizerEffective glass atomizerLamp standEight lampsD2 background correction abilityWhen the background is 1 A, the background ability should be deducted not less than 50 times; self absorption background deduction methodSize and weight700mm×550mm×450mm 75KgPower source220V±22V AC




Flame System:

Acetylene air burner100mmNitrous oxide acetylene flame head50mmIgnition dynamic baseline drift≤0.006A/30min(Cu) Characteristic viscosity≤0.025μg/ml/1%Related standard deviation of the accuracy≤0.5%(Cu, absorbance>0.8A) (detection limit Cu≤0.008μg/ml)Safety systemCan automatically cut off the gas when the pressure is not enough, the power is off, flameout and unconformity of the burner




Graphite Furnace:

The highest temperature3000ºCThe largest temperature rising speed≥2000ºC/SCharacteristic quantityCd≤0.5×10-12g Cu≤0.5×10-11gAccuracyCu≤3% Cd≤3%Size and weight550mm×450mm×300mm 65KgSafety systemOver current protectionProtectionLow air pressure alarm, low cooling water flow alarmPower source and power220V±22V AC 7000W






Factory overviewFlame Aas Atomic Absorption Spectrophotometer with Graphite Furnace
Customer Feedback

Germany
Flame Aas Atomic Absorption Spectrophotometer with Graphite Furnace
USA
Flame Aas Atomic Absorption Spectrophotometer with Graphite Furnace
Package
Flame Aas Atomic Absorption Spectrophotometer with Graphite Furnace
FAQ
1.What's the delivery time?
About 25 days.

2.What's your payment terms?
30% paid by T/T in advance,70% paid by by T/T before shipping.

3.What's your guarantee terms?
The warranty of all products is 1 year.During this period,we are responsible for all faults caused by us.And we can supply life-long technical support.

4.Can you supply training?
We can supply training in our factory and online training for free.If onsite installation and training are required,please pay for tickets,accommodation and salary USD150/Day for every perso
