GD6100B New Design Transformer Insulating Oil Dielectric Dissipation Tester
HV Hipot Electric Co., Ltd.- After-sales Service：yes
- Warranty：1 year
- Type：Universal Testing Machine
- Load Way：Electronic Load
- Loading Method：Dynamic Load
- Display：Digital
Base Info
- Model NO.：GD6100B
- Control：Computer Control
- Weight：0-100Kg
- Power Source：AC220V
- Oil Cylinder Position：Top
- Measuring range：Capacitance: 5PF~200PF
- Relative Permittivity：1.000~30.000
- Dielectric loss factor：0.00001~100
- Transport Package：Wooden Box
- Specification：460mm*370mm*330mm
- Trademark：HV Hipot
- Origin：Wuhan, China
- HS Code：9030899090
- Production Capacity：3000set,Year
Description
Voltage supply
AC 220V±10%
Power frequency
50Hz/60Hz ±1%
Measuring range
Capacitance
5pF~200pF
Relative Permittivity
1.000~30.000
Dielectric loss factor
0.00001~100
DC Resistivity
2.5MΩm~20TΩm
Measuring accuracy
Capacitance
± (1% of reading+0.5pF)
Relative Permittivity
±(1~10)% of reading
Dielectric dissipation factor
± (5% of reading+0.0002)
DC Resistivity
±10% of reading
Resolution
Capacitance
0.01pF
Relative capacitivity
0.001
Dielectric dissipation factor
0.00001
Measured temperature range
0~120ºC
Temperature measurement error
±0.5ºC
AC Test Voltage
200~2200V Continuously adjustable, frequency 50Hz
DC Test Voltage
0~500V Continuously adjustable
Power consumption
100W
Ambient temperature
0ºC~40ºC
Relative humidity(RH)
<75%
Dimensions
450mm×410mm×320mm
Total weight
25KG
