Variable Resistor Battery Load Bank
Hebei Kaixiang Electrical Technology Co., Ltd.- After-sales Service：1 Year
- Warranty：12 Months
- Type：Battery Load Bank
- Test Region：All
- Customized：Customized
- Voltage：48V
Base Info
- Model NO.：ZNF48-200
- Max Current：200A
- Protection Voltage：60V
- Cooling：Forced Air Cooling
- Ambient Temperature：-20ºC - +50ºC
- Certification：Ce ISO
- Transport Package：Plywood Case
- Specification：1 cmb
- Trademark：TriumphLoad
- Origin：China
- HS Code：9030339000
- Production Capacity：2000 Sets, Per Year
Description
Battery bank nominal voltage
DC48V, peak voltage 60VDC
Discharge Voltage
At 48±15% can discharge the highest current 200A. Discharge for short time when voltage > rated voltage+10%. Current will decrease if voltage < rated votlage-10%.
Protection voltage
1-60V
Discharge Current
1-200A
Discharge Time
1M---99H59M
Discharge Capacity
1-9999Ah
Total Voltage Testing Accuracy
±1%
Current Adjust Accuracy
±1%
Constant Current Discharge Control Accuracy
±(0.3%+0.2A)
Working Power Supply
AC220V/50Hz
Cooling
Forced air cooling, horizontal air inlet, horizontal air outlet
Ambient Temperature
-10ºC - +40ºC
Dimension
About the 1450mm *570mm *870mm
Weight
Approximately; 400kg
