• Model NO.：FZ-814
• Transport Package：Wooden Case
• Specification：See specifications
• Trademark：SEREV REAL
• Origin：China
• HS Code：9031809090
• Production Capacity：800sets,Year

Basic Info.

Model NO. FZ-814 Transport Package Wooden Case Specification See specifications Trademark SEREV REAL Origin China HS Code 9031809090 Production Capacity 800sets/Year

Product Description

Model	FZ-814D
Standards	FZ/T 60017  GB/T 24218.8 GB/T 24218.13  GB/T 24218.14

This equipment is used to determine the liquid (simulated urine) penetration properties of nonwoven coverings.


Features

Color touch screen control, Chinese and English menus, man-machine dialogue mode, easy to operate.
Built-in thermal printer, convenient to quickly print test results on site.
The penetrating disc adopts special plexiglass through special processing.
All data and statistical results can be freely viewed in the host.
The penetrating disc is equipped with a precise positioning device to avoid collision and damage.
The penetrating disk electrode is corrosion-resistant.


Specification

Flow rate of funnel with solenoid valve	flow through 25ml in (3.5±0.25)s
Penetration times	1 to 5 times can be set
Interval setting time	20~99s (arbitrary setting)
Substrate material	transparent material plexiglass
Substrate size	125×125mm, thickness about 5mm
Penetrating disc size	100×100×25mm
Penetrating disc weight	500g±5g
Electrode diameter	1.6mm
Sample size	100×100mm
Dimensions	410×370×500mm
Weight	22kg
Power supply	AC220V 50Hz 50W




                                                      Paper powder-drop tester
