• Model NO.：HDFD-4840W
• Rating Voltage/Frequency：AC 400V,50Hz, 3 Phase 4 Wire
• Max Load Power：Resistive Load: 310kw
• Power Supply：380VAC 3 Phase 4 Wire 50Hz
• Communication Interface：RS485, RS232
• Transport Package：Wooden Box with Foam Inside
• Trademark：HD Power
• Origin：Made in China
• HS Code：9030899090
• Production Capacity：800,Month

Basic Info.

Model NO. HDFD-4840W Rating Voltage/Frequency AC 400V/50Hz, 3 Phase 4 Wire Max Load Power Resistive Load: 310kw Power Supply 380VAC 3 Phase 4 Wire 50Hz Communication Interface RS485, RS232 Transport Package Wooden Box with Foam Inside Trademark HD Power Origin Made in China HS Code 9030899090 Production Capacity 800/Month

Product Description

HDFD- 4840W DC Load Bank Test System


Technical parameter


Rated Voltage	480V DC
Rated Current	400A  not need CC Mode Discharge
Load Steps	Total 400A Resistive Load:5 steps; 1, 2, 2, 5, 10,20,20,50,100,200A
Load Accuracy	±5%
Sampling	0.5 class
Display	Digital meter display voltage/ current / power
Protection Function	Over current protection, over voltage protection , Emergency stop button , over- temperature protection , sound and light alarm
Wire Connection	Testing Battery : Copper bar (+ -) Control Power : Power Cord Socket
Work Mode	Continuous work
Cooling mode	Force-air cooling
Control power	Power Supply for fan (230V 50Hz) single phase
Control Mode	Local Manual Control
Mode Mode	Movable , 4 wheels for easy moving
Ambient	-10 ºC ~  +50 ºC
Relative Humidity	≤95%
Altitude	≤2500 meters
