3-Zone High Low Temperature Programmable Thermal Shock Test Chambers
Guangdong Komeg Industrial Co., Ltd.- Power Supply：AC380V ,AC220V 50Hz
- Certification：CE, ISO
- Warranty：1 Year
- Test Weight：10kg
- Interrior Material：500*450*450mm
- Exterrior Material：1540*1840*1700mm
Base Info
- Model NO.：KTS-A Series
- Conversion Time：5 Mins
- Chamber Quantity：3 Zones
- Testing Samples：Can Be with Load
- Transport Package：Strong Plywood Case, Meet International Standard
- Specification：Standard and customized, ISO9001, SGS, CE, TUV, UL
- Trademark：KOMEG
- Origin：Dongguan, China
- HS Code：90321000
- Production Capacity：1000 Sets Per Yesr
Description
SpecificationsNote:1. We reserve the right to change specifications without prior notice 2. Customized sizes and configurations available Model KTS-A Series KTS-B Series KTS-D Series 72A 100A 150A 200A 252A 300A 480A 72B 100B 150B 200B 252B 300B 480B 72D 100D 150D 200D 252D 300D Interior size W(mm) 450 500 600 670 700 800 800 450 500 600 670 700 800 800 450 500 600 670 700 800 H(mm) 400 450 500 600 600 600 800 400 450 500 600 600 600 800 400 450 500 600 600 600 D(mm) 400 450 500 500 600 650 750 400 450 500 500 600 650 750 400 450 500 500 600 650 Exterior size W(mm) 1490 1540 1640 1720 1750 1850 1850 1490 1540 1640 1720 1750 1850 1850 1490 1540 1640 1720 1750 1850 H(mm) 1790 1840 1890 2000 2000 2000 2200 1790 1840 1890 2000 2000 2000 2200 1790 1840 1890 2000 2000 2000 D(mm) 1600 1700 1830 1850 1930 1980 2500 1600 1700 1830 1850 1930 1980 2500 1600 1700 1830 1850 1930 1980 Test weight(KG) 5 10 12 15 18 20 20 5 10 12 15 18 20 20 5 10 12 15 18 20 Low Temp. chamber -55ºC~-10ºC -70ºC~-10ºC -80ºC~-10ºC Pre-heat time +20ºC~-55ºC ,Within 60 min +20ºC~-70ºC ,Within 60 min +20ºC~-80ºC ,Within 60 mins Test. chamber -40ºC~+150ºC -55ºC~+150ºC -65ºC~+150ºC High Temp. chamber +60ºC~+200ºC Pre-heat time +60ºC~+200ºC ,Within 20 min Recovery time High-Temp Exposure 30 min Low-Temp Exposure 30 min Recovery time within 5 min Safety device No fuse breaker, over pressureover heat and over current protection for compressor,over temperature protection, over load protection for blower, dry heat protection Standard accessory Cable port(portΦ50mm)*1, shelves*2 Interior material Stainless steel plate(SUS 304) Exterior material Baked painting steel or stainless steel(SUS304) Insulation material Rigid polyurethane Foam+glass fiber wool Refrigeration system Water Cooled Semi-hermetic compressor, cascade refrigeration system, CFC free refrigerant(HFC-507 and HFC-23) Controller Panel:7-inch LCD Touch panel,Chinese or English display selectable Operation model:Program or fix point running Memory capacity:120programs,1200steps,all repeat 999cycles,part repeat 99 cycles. Accuracy:Temp.:0.1% of F.S±1 digit Humidity:0.1% of F.S±1 digit Input:Temp.:pt-100 Humidity:pt-100 or ~5V DCV Ambient Temp. +5ºC~+35ºC Power AC 380±10%50Hz ,3 phase 4 wires +Ground Wires
