Laptop Battery Burn-in Test Chamber
GUANGDONG BELL EXPERIMENT EQUIPMENT CO., LTD.- After-sales Service：24 Hours Online
- Power Supply：AC220V
- Certification：CE, ISO
- Warranty：1 Year
- Burner：Bunsen Burner with Inner Diameter of 0.375 Inch (9
- Flame Application Time：99h 59m 59s
Base Info
- Model NO.：BE-8105
- Mesh Top Cover：Square Shape with Length Approx. 650mm
- Transport Package：Each Set Protected with Resin Fiber and PP Film, T
- Trademark：DGBELL
- Origin：Guangdong China
- HS Code：9031809090
- Production Capacity：100set ,Month
Description
Model
BE-8105
Structure
All-in-one structure, the door uses explosion-proof lock and explosion-proof chain
Burner
Bunsen burner with inner diameter of 0.375 inch (9.5mm) and length approx. 100mm
Flame Application Time
99H 59M 59S
Flame Height
*10~75±2mm(Adjustable)
*Mesh should be placed approx. 38mm above the flame (GB31241-2014)
Test Rod Diameter
1/4inch(6.35mm)× 14inch(355.6mm)
Octagon Shape Stainless Steel Mesh Enclosure
Distance between each parallel sides: 24 inches (610mm)
Height: 14 inches (305mm),
Angle iron : spec. 12.7mmX12.7mm
Mesh Top Cover
Square shape with length approx. 650mm
Test Aluminum Mesh Specification
0.010inch (0.25mm) 16 grit x16 grit
Test Round Hole Surface Diameter
102mm
Ignition Device
Automatic ignition
Display Mode
PLC touch + Remote control
Observation window
390x360mm (20mm thick explosion-proof glass, install explosion-proof stainless steel mesh)
Control Method
Remote control, automatic control through the entire test.
Combustion Gas Requirements
High purity liquefied petroleum gas. (Prepared by user)
Data Output
Test data can be output by USB flash disk directly .
Safety Protection
Explosion-proof pressure relief device, smoke exhaust device, fire extinguishing system, electronic door lock system, safety stop switch
Options
Temperature acquisition system, voltage acquisition system, video monitoring system
Established in 2005, Guangdong Bell Experiment Equipment Co., Ltd is specialized in manufacturing a variety of quality inspection instruments, testing equipments and other high-tech products which mainly include: Constant Temperature & Humidity Test Chamber,High & Low Temperature Test Chamber, High & low Temperature Testers with Rapid Temperature Change, Walk-In humidity & temperature test chamber, Cool/Thermal shock test chamber, Salt spray chamber, High temperature aging tester, sand and dust testing machine,tension tester, high and low temperature testing machine , servo computer battery crush tester, mechanical vibration testerBattery washing tester ,battery burning tester and other quality testing instruments. Thanks to several decades of R&D efforts,the company has established itself as a leading provider of testing instruments of the industry, playing a crucial role in the research and development of high-quality and high-value products within the industry.
15+ years experience in test chambers manufacturing, High performance for your projects.
With unmatched quality advantage, a dynamic management team, professional customer services, superb manufacturing techniques and innovative research and development ideas, Guangdong Bell Experiment Equipment Co., Ltd, supported by an international, standard and professional quality policy, is gradually becoming an international brand. Its products are manufactured in consistent with a number of world standards.
