High Precision Electric Heating Oven for Motor Speed Test
Guangdong Yuanyao Test Equipment Co., Ltd.- Type：Material Testing Machine
- Maxcapacity：<1000KN
- Accuracy Grade：0.5
- Load Way：Electronic Load
- Loading Method：Dynamic Load
- Display：Digital
Base Info
- Model NO.：YPO-480
- Control：Controller
- Weight：100-500Kg
- Power Source：AC380V
- Oil Cylinder Position：N,a
- Inner Size：800*1000*600mm
- External Size：1200*1700*840mm
- Volume：72 Liters
- Temp. Fluctuation：+,-0.3 Degree
- Color：Ivory
- Interior Chamber Material：SUS#304 Stainless Steel Plate
- Exterior Chamber Material：Stainless Steel Plate + Powder Coated
- Circulation System：Circle Fan
- Indication Resolution：0.1degree , 1 Degree
- Heat up Time：60 Mins
- Transport Package：Strong Wood Carton
- Specification：YPO-072
- Trademark：Yuanyao
- Origin：China
- HS Code：9032100000
- Production Capacity：100 Sets,Month
Description
MODELYPO-072 YPO-270 YPO-480 YOP-600 YPO-720 Internal Sim.WHD(mm) 450×400×400 600×900×500 800×1000×600 1000×1000×600 1200×1000×600 External Dim.W×H×D(mm) 870×1200×550 1050×1650×740 1200×1700×840 1400×1750×840 1750×1750×840 Temp.Range Room Temp.+10ºC---+200ºC(300ºC) Ferformance Temp.&Humi,Constancy ±0.3ºC Temp.&Humi,Constancy ±0.1ºC AT 200ºC;±1.5% AT 300ºC Indication Resolution 0.1ºC/1ºC Heat-up Time( min.) Approx.60min. Material Exterior Iron Sheet+Baked Enamel Interior SUS#304 stainless steel piate Insulation Fiberglass Wool SYSTEMS Cirulation Circle Fen Heating Chrome Steel Strip Wire Heater Controller Electric Digital Control+S.S.R. door Single-Wing Double-Wing Other Components Environmental Control Indicator Lights, Experiment Separation Shelves(2 pcs). Sevey Devices Overheating Prevention Circuit breaker, Control System,Breakdown Indicator Light. Power Source[K.W.] AC 1Ψ 220V ; 3Ψ 380V 60/50Hz Any requested size and TEMP. range(max.1200ºC)will be considered.
