Pnshar Paper Honeycomb Compression Tester
Hangzhou Pnshar Technology Co., Ltd.- Type:Compression Testing Machine
- Weight:0-100Kg
- Power Source:AC220V
- Transport Package:Seaworthy or Airworthy Package
- Specification:ISO, ASTM, TAPPI
- Trademark:PNSHAR
Base Info
- Model NO.:PN-HF300F
- Origin:China
- HS Code:90248000
- Production Capacity:100sets,Month
Description
Basic Info.
Model NO. PN-HF300F Origin China HS Code 90248000 Production Capacity 100sets/MonthProduct Description
Introduction:PN-HF300F honeycomb board crush tester is a new type high-precision intelligent tester researched and developed by our company in accordance with relevant national standards. It is mainly applicable to the flat compression strength (FCT) of honeycomb fiberboard with a thickness of 5.0mm ~ 40.0mm. It is a tester with very high cost performance in China. Flat compression strength: The maximum pressure per unit area, expressed in kilopascals (kPa).
The compressive strength mainly affects the cushioning performance of the honeycomb fiberboard. The higher the compressive strength, the better the cushioning performance of the honeycomb carton made. Honeycomb fiberboard has a much higher compressive strength than corrugated paperboard. In addition to making honeycomb box, honeycomb fiberboard is also a good cushioning material to protect products.
This tester is an electromechanical integration structure, and adopts modern mechanical design concept and microcomputer processing technology for careful and reasonable design. The tester adopts the fixing upper platen, with high measurement accuracy. PN-HF300F honeycomb fiberboard strength tester has functions of parameter testing, conversion, adjustment, memory, pressure curve real-time display, data printing and other functions included in the standard. It has powerful data processing functions, can directly get the statistical results of various data, and can automatically reset, easy to operate, easy to adjust, and stable performance.
Features:
1. High speed return after finishing test.
2. Imported step motor with servo control adopted
3. The test result can be measured, statistical and printed automatically and the data can be saved.
4. Blue color LCD display, which can be display the crush time and loading force real time, PN-HF300 type can display crush graph real time.
5. New PC software able to manage and analyse the data and can communicate with PC. (Only for PN-HF300 type). Thermal printer, high speed and no noise.
6. Use the modern design idea of mechanical and electrical integration, which has compact configuration, pleasing appearance and convenient maintenance.
NO. | ITEM | SPECIFICATION |
1 | Power supply: | AC220V±10% 2A 50Hz |
2 | Error of indication: | ±1% |
3 | Resolution: | 0.1N |
4 | Measuring range: | (5~ 3000)N |
5 | Sampling size: | Length or diameter of 60mm or at least 4 complete lattice. |
6 | Parallelism: | ≤0.05 mm |
7 | Max distance: | (2~ 70)mm |
8 | Test speed: | 1 mm/min |
9 | Return speed: | (5~ 40) mm/min |
10 | Display: | LCD Display and English menu |
11 | Printer: | Thermal printing, high speed and no noise |
12 | Data output: | RS232(Standard) / USB(Optional) |
13 | Work environment: | Temp.(20 ± 10)°C relative humidity< 85% |
14 | Dimension: | (375 × 345 × 505)) mm(L×W×H) |
15 | Net Weight: | About 38.6 kg |
