• Model NO.：HT-7114
• Weight：100-500Kg
• Power Source：AC220V
• Speed：20-30mm,Min
• Stroke：500mm
• Capacity：200kg
• Materials：Stainless Steel and Aluminum Alloy
• Function：Mattress Testing Machine
• Transport Package：Strong Wooden Case
• Specification：Max mattress size(L*W*H): 2200*2200*40mm
• Trademark：HOTOTECH
• Origin：Dongguan, Guangdong Province
• HS Code：9013809000
• Production Capacity：100 Sets Per Month

Basic Info.

Model NO. HT-7114 Weight 100-500Kg Power Source AC220V Speed 20-30mm/Min Stroke 500mm Capacity 200kg Materials Stainless Steel and Aluminum Alloy Function Mattress Testing Machine Transport Package Strong Wooden Case Specification Max mattress size(L*W*H): 2200*2200*40mm Trademark HOTOTECH Origin Dongguan, Guangdong Province HS Code 9013809000 Production Capacity 100 Sets Per Month

Product Description

Mattress Testing Machine
Testing Machine for Mattress Purpose
Use a spherical protruding at the bottom of the circular rigid plate loading, record force curve and displacement to analysis, then assess the mattress hardness values and hardness levels.
The machine produced by aluminum, beautiful appearance. Special high-precision intelligent ARAM controller. It can run under Windows system with a dedicated test software, clarity interface, easy operate.

Testing Machine for Mattress Specification
1. Load block: Diameter 355 mm, Spherical radius of curvature 800mm
Front edge radius of curvature 20mm
2. Speed: 20~300mm/min
3. Stroke: 500mm
4. Capacity: 200kg
5. Load plate position adjustment: 300mm
6. Max mattress size(L× W× H): 2200× 2200× 40mm



Speed	20~300mm/min
Stroke	500mm
Capacity	200kg
Load plate position adjustment	300mm
Max mattress size(L× W× H)	2200× 2200× 40mm
