General Charpy Impact
Suzhou Qiantong Instrument Equipment Co., Ltd.- Max Diameter of Workpiece：4mm
- Mass Scope of Workpiece：<900kg
- Type：Impact Testing Machine
- Maxcapacity：<1000KN
- Accuracy Grade：0.5
- Load Way：Electronic Load
Base Info
- Model NO.：QT-5201 Series
- Loading Method：Dynamic Load
- Display：Digital
- Control：Manual Control
- Weight：60kg
- Power Source：AC220V
- Oil Cylinder Position：Electronic
- Transport Package：Wooden Case
- Specification：420*250*650mm
- Trademark：SUZHOU QIANTONG
- Origin：Jiangsu, China
- HS Code：9024800000
- Production Capacity：1000 Set,Year
Description
QT-5201Charpy Impact console 1 set Qiantong screen 1 set Wei Lun Tong Tai PLC 1 set German control system swing 1 set Qiantong weight 1 pair Qiantong gradienter 1 piece Qiantong fixture jag 2 pieces (including the on on fixture mount) Qiantong middle sample plate 1 piece Qiantong power line 1 piece Qiantong Instruction book 1 piece Qiantong Quality certificate 1 piece Qiantong Inventory list 1 piece Qiantong
FAQ
Q:Are you a trade company or factory?
A:Our company is a factory and directly sales.
Q:Can your company accept customization?
A:Yes. Our machines can be customized by client.
Q:How to guarantee your after-sales service?
A:Our philosophy is one year warranty and lifetime service. After the warranty period is exceeded, if there is any problem, we will provide support for you in time. (only charge travel expense and parts cost at most.)
Q:What is the language about software?
A:It can switch between Chinese and English.
Q:May the customer not use your company's computer?
A:Sure. But please tell us what type your computer is. We need to confirm your computer can install the software. And we can subtract the price of computer from offer.
Q:Can the machine be upgrade?
A:Yes, it can.
| Impact speed | 2.9m/s |
| Impact energy | 2J 4J 5J |
| Impact angle | 150; |
| Radius of rounded corner of impact blade | R=2mm |
| Angle of impact blade | 30±1º |
| Round corner radius of jaws | 1.0±0.1mm |
| Distance between jaws support lines | 62mm |
| Moment of impact pendulum | pd0.5=0.26795Nm pd1=0.53590Nm pd2=1.07180Nm pd4=2.14359Nm pd5=2.67949Nm; |
| Distance of center of percussion | 230mm |
| Sample size | 80×10×4mm |
| Shape size | 420×250×650 |
| Power | 220V 50Hz 200W |
| Meet standards | GB1043-92, ISO179 |
| Weight | 60kg |
