Motor Operated Dynamic Cone Penetrometer
Zhuozhou Tianpeng Imp. & Exp. Trade Co., Ltd.- Produce Standard:DIN 4094 Lrs10 Uni Env 1997-3
- Hammer Weight:10kgs
- Falling Distance:20cm. Fall
- Transport Package:Wooden Box
- Specification:20,30 kg hammer
- Trademark:C-Tech
Base Info
- Model NO.:16-T0012,D
- Origin:China
Description
Basic Info.
Model NO. 16-T0012/D Origin ChinaProduct Description
Model 16-T0012/D FEATURES:• The apparatus comprises a 4 stroke engine which drives, through a fl exible shaft, the lifting mechanism, a
20 kg weight, a 10 kg supplementary weight, 10 rods, 5 cones each of 500 and 1000 mm2 size, and rod lifting
device.
• Accessory 16-T0012/D7 Tripod to make easier the use of the apparatus.
• 1.9 kW 4 stroke engine
• Driving rate: up to 45 blows/min
• One year warrantee against any manufacturing defects.
COMPRISES:
16-T0012/D1 Hammer, 20 kg
16-T0012/D2 10 kg supplementary weight
16-T0012/D3 Drive conical point, 500 mm2 area, 25.2 mm dia, 90° angle
16-T0012/D4 Sounding rod 22mm dia.
16-T0012/D5 4 stroke engine
16-T0012/D6 Lever device for rod extraction
16-T0012/D7 Tripod for hanging the lifting mechanism. including 16-T0012/D6,16-T0012/D7
and 16-T0012/D8
Max. height 2300mm; Weight approx: 18 kg
16-T0012/D8 Hand winch
16-T0012/D9 Hook
16-T0012/D10 Height adjustment lever
Weight: 70 kg approx. (without sounding rods and accessories)
