Best Popular Melt Rate Flow Meter Melt Flow Rate Tester for Laboratory Use
Jinan Chenji International Trade Co., Ltd.- After-sales Service:Whole Life
- Certification:TUV
- Power:Electronic
- Warranty:1 Year
- Style:Desktop
- Application:School, Lab
Base Info
- Time Range:0-999s
- Temperature Control Range:50-450degree
- Accuracy:± 0.2 ºC
- Resolution:0.1 ºC
- Sensor Measurement Range:0 - 40mm
- Accuracy 1:± 0.05mm
- Dimensions:550 × 370 × 600mm
- N.W.:25kgs
- Weight of The Host:21.6 Ks
- Transport Package:Standard Package
- Specification:500*300*800
- Trademark:Chenji or OEM
- Origin:China Jinan or Others
Description
Barrel parameters
Inner hole 9.55±0.025mm
Pistons parameters
Piston head: 9.475±0.015mm
Piston length
H=6.35±0.1mm
Parameters
Extrusion hole 1=2.095±0.005mm
Temperature parameter
With intelligent temperature control instrument, with four pairs of significant temperature setting control, PID parameters can be automatically set, precision up to ± 0.1 degree centigrade
Temperature range
400ºC
Temperature rating
±0.2 ºC
Display resolution
0.1ºC
Maximum consumption
< 600W
Temperature recovery time
less than 4 min.
Weight accuracy
±0.5%
Basic configuration
0.325kg, 1.2kg, 2.16kg, 3.8kg, 5.0kg, 10.0kg, 12.kg, 21.6kg
Loop distance from up and down
30mm
Control precision
± 0.1mm
Times of cutting the material
0~10 times
Material cutting interval
0~999s(set reference Table 2)
Barrel temperature time
15 min.
Material be installed
1 min
Material sample temperature recovery time
4 min.
When binder set
1min
