• Model NO.：VS-5060
• Maximum Payload：80kg
• Test Mode：Fix; Sweep;Multi-Random
• Displacement Range：0~2.8mm P-P Adjustable
• Table Size：500*600(mm)
• Test Program Number：No Limit
• Test Time：No Limit
• Vibration Dimensions：W625*D525*H690mm
• Transport Package：Strong Plywood Case for Long Journey Delivery
• Specification：Standard and Customized
• Trademark：KOMEG
• Origin：Dongguan, China
• HS Code：90321000
• Production Capacity：1000 Sets,Year

Basic Info.

Model NO. VS-5060 Maximum Payload 80kg Test Mode Fix; Sweep;Multi-Random Displacement Range 0~2.8mm P-P Adjustable Table Size 500*600(mm) Test Program Number No Limit Test Time No Limit Vibration Dimensions W625*D525*H690mm Transport Package Strong Plywood Case for Long Journey Delivery Specification Standard and Customized Trademark KOMEG Origin Dongguan, China HS Code 90321000 Production Capacity 1000 Sets/Year

Product Description

Environment Friendly Mechanical Vibration Test Machine:
Specifications
1. Humidity vibration test chamber;
2. High accurate value;
3. Siemens PLC controller;
4. Colour LED display

Use four points synchro reverse direction, good uniformity for the test table
Frequency is adjustable free, can meet different test specimen requirements
Double Chinese and English windows standard control interface

Why should you choose KOMEG?
1. Dedicate touch and excellent user experience;
2. Unique and compact design, top grade appearance, stable performance and easy operation;
3. Can simulate a wide range of temperature and humidity environments;
4. Capable of testing large components, assemblies, and finished products;
5. Customized sizes and comfigurations available;
6. One year warranty

Each product have to experience is to be transported from one place to another.
How do you know your products can survive this vabration without?

Vibration test machine is widely applicable to the defense, aerospace, communications, electronics, automobiles, household appliances and other industries.
Temperature and humidity test chamber matched with appropriate vibration test bench to meet with respective corresponding

The following is the technical parameter:

Model	VS-5060
Frequency range	10-80Hz
Frequency accuracy	±0.05Hz
Acceleration range	0 ~ 11G(peak)
Maximum Payload	80kg
Test Mode	Fix ; Sweep ; Multi-random
Displacement range	0 ~ 2.8mm p-p, adjustable
Table size	500*600mm
Test program number	No limit
Test time	No limit
Power	AC220V 1Φ 50Hz 5A
Vibrator dimensions	W625*D525*H690mm
